Transparent Polycarbonate Film
PC6811
Feature:
- Heat Resistance
PC film with good heat resistance can be widly used in many fields. Mechanical properties are changed as per termperature, which is favorable to strength design.
- Impact Resistance
PC film is a type of engineering plastic with the super impact resistance. Even if it’s in -40℃ environment, the impact resistance is as well as in normal temperature.
- Flame Resistance
PC film with flame resistance is widely applied in applied in appliance, automobile, electronics, aviation, luggage etc.Besides, The level of flame resistance is 94 V-2 and V-0.
- Transparency
Clear PC film with excellent transparency in high transparent materials, which are widely applied in printing and optics instead of inorganic glass. The light transmission is 89%-92%.
Description
PC film is short for Polycarbonate film. It is an amorphous, odorless, non-toxic, highly transparent colorless or slightly yellow thermoplastic engineering plastic.
Typical Property Values
|
Property |
Testing Method |
Testing Condition |
Units |
Value |
| Physical | ||||
| Specific Gravity | ISO 1183 | —— | G/cm3 | 1.2 |
| Light Transmission | ASTM D1003 | —— | % | >89 |
| Water Absorption Equilibrium | ASTM D570 | 24 Hours | % | 0.35 |
| Mechanical | ||||
| Tensile Strength | ISO527 | —— | Mpa | 60 |
| Tensile Modulus | ISO527 | Mpa | 2400 | |
| Flexural Modulus | ISO178 | Mpa | 92 | |
| Temperature Resistance | ||||
| Vicat Softening Temperature | ISO306 | ℃ | 148 | |
| Thermal expansivity | ISO11359 | /℃ | 6.5*10-5 | |
| Electrical | ||||
| Permittivity | IEC60250 | —— | 3.1 | |
| Voltage test | IEC60243 | KV/mm | 30 | |
| Volume Resistivity | ICE60093 | 25℃,50%RH | Ω.cm | 1016 |
| Surface Resistivity | ICE60093 | 25℃,50%RH | Ω | 1017 |
| Gaute Variation | >0.5mm ±3% | |||
| 0.25—0.5mm ±5% | ||||
| 0.1—0.25mm ±10% | ||||
| ≤0.1mm ±0.008mm | ||||
Note: The above figures are typical values obtained under standard methods and should not be construed as unsteady application conditions.
Application:
Widely used in such as: the hat, sunglass, windows, aviation sheet, lighting, electroplating, vacuum forming, dyeing, etc.
