High Brightness Outdoor LED Billboard Advertising 8mm Pixel Nichia Or Epistar Chip
High Brightness Outdoor LED Billboard Advertising 8mm Pixel Nichia Or Epistar Chip
The indoor LED display can display colorful dynamic and static images in real time with perfect display effect. Thus, this LED display is the most significant display in all indoor full color screens.
The LED display supports usual VGA and DVI tradational video signal, also specially supports HDMI video signal and so on. In addition, it can receive and display video programs, such as TV programs, VCD or DVD, living show etc.
The products has high reliability, saturated and uniform color, hight brightness, low consumption, long service life and with wide angel sight. So the SMD full-color 3 in 1 indoor LED display is widely used in many indoor sites, such as show rooms, coffee house, hotel, stage and so on.
>> Specification and Parameter
| Technical DataModel | PH8 |
| Pixel Pitch | 8mm |
| Physical Density(pixels/m²) | 15625 |
| LED Shape & Size | SMD 3 in 1 |
| LED Arrangement | 1R1G1B |
| Module Size(mm) | 256×128 |
| Module Resolution | 32*16 |
| Drive Mode | Dynamic 1/4Duty Constant Current |
| Brightness | ≥5500cd/m² |
| Contrast(cd/m²) | ≥2000:1 |
| View Angle, 50% Brightness | 140°/140° |
| Minimum View Distance | 8m |
| Grey Scale | 10bits/1024levels |
| Color Capacity | 1.07billion |
| Maximum Power Consumption | 1200W/m² |
| Ave.Power Consumption | 320W/m² |
| Operation Power Source | AC90-260V 50-60HZ |
| Frame Frequency | 60-85HZ |
| Refresh Rate | 240-1000HZ |
| Brightness Adjustment | 0-100% 8 levels automatic |
| Gamma Correction | -5.0-5.0 |
| Correction Scale Level | 16bits |
| Color Temperature | 5000-9300K |
| Brightness Correction | Pixels, Module, Cabinet Correction |
| Input Source Support | Composite, S-Video,Component,VGA,DVI,HDMI,SDI, HD_SDI |
| Control Distance | UTP CAT5E:100m;Multi-mode Fiber:50m;Single-mode Fiber:10km |
| Operating Temperature | -40°C - 65°C |
| Operating Humidity | 10-90%RH |
| Operating Life Span | 100,000Hours |
| MTBF | 5000 Hours |
| Protection Ratings | IP65 |
| Out of Control Rate | 0.01% |
>> Advantage
1. High Contrast:4000:1.
2. First-class LED chip: Epistar from Taiwan
3. Clear vivid image quality even in direct,full-on sunlight.
4. Long-term Brightness capacity throughout product lifetime.
5. Easy Installation & Using.
6. Convenient Servicing.
7. Source compatibility: CVBS,YC, YUV,RGB, DVI, SDI, HD-SDI, HDMI
