Seamless Splicing Outdoor LED Billboard Full Color P8 SMD Stadium Big Screen

 Our Advertising LED Display are designed with features of thin, lightweight, flexible; Simple and durable structure,500*1000*68 mm cabinet, 13 kg/panel, could be fast to install and dismantle by one man in a short time without gap. Mostly used in creating large-area backstage, such as Stage, TV Show, Nightclub, etc. The screens and image revealed are true and beauty, creating a dream effect. An series are the best choice of creative designing company.

 1. Pixel
 Pixel LED: SMD 3528
 Pixel Configuration: 1R, 1G, 1B
 Wave length(nm): R: 626-628, G: 518-520, B: 466-468
 Pixels Pitch(mm): 8

 2. Module
 Module Size(mm): 256 * 128 * 20
 Module Pixels (DOT): 32 * 16

 3. Unit box
 Module quantities(PCS/box): 4 (L) * 6(H)
 Unit box size(mm): 1024(L)* 768(H)* 180
 Unit box Pixels(DOT): 128 * 96
 Unit box material: Aluminum or Iron
 Weight (kg/box): Aluminum: 35 or Iron: 42

 4. Packaging
 Packing Way: Two unit boxes packed into one
 Packing box material: Wooden case or Flight box
 Packing box size (mm): 1150 * 950 * 480

 5. Electricity parameter

 Pixel density(dots/m2): 15625

 White Balance Brightness(CD/m2): ≥1000

 Color temperature(K): 5000_9500 (choice by user)

 Brightness Adjusted: 100 grade by software, or by Auto-optic induced.

 View Angel: Horizontal 160; Vertical 140

 Best viewing distance(m): 2-80

 Communication distance (m): Internet Wire: 120 Fiber Cable: 1000

 Screen work Method: Scan: 1/4

 LED driving method: Constant driving current

 Gray Grades: 16384 levels for each color

 Switch power supply: Switch power supply (include CE/GS or UL/CSA certificate) 110V/60Hz, 220V/50Hz

 Power Consumption (w/m2 ): Max: 800, Average: ≥500

 >> Advantage

 (1) High brightness reach to 8000CD.

 (2) High Refresh Rate reach to 5000Hz or more

 (3) Long lifespan and stable quality

 (4) Aluminum Material

 (5) Working under the temperature -30C to +75C

 (6) Save 35% power than normal screens
