Total Automatic Tube Filling And Sealing Machine High Speed For Facial Mask
HIGH SPEED FULLY AUTOMATIC FACIAL MASK FILLING AND SEALING MACHINE
High speed automatic facial mask filling sealing machine
It controlled by micro-computer with linear design and engine of famous brands like Schneider and OMRON and equipped with German PLC system. The volume calculation of this machine is precise with easy handing. Its sealing system is controlled by intelligent temperature controller with high qualified rate. This machine is special designed for facial mask factory with professional research, compact structure and easy operation, which can fulfill the whole packing process of facial mask production with no dripping. Moreover, one worker can handle two machines at the same time.
Working Processes
Auto Packing Locating - Auto Filling - Auto Sealing - Auto Printing - Finished
Technical features:
1. automatic bag, fill, seal, code and output;
2. It’s made of stainless steel 316, which is in accordance with the GMP standard.
3. according to the nature of the material selection of different filling machine, marked as an electronic gear pump, pneumatic piston pump as a selection, suitable for high viscosity of the mask liquid filling;
4. no bags, no filling; no bags, no seal, sealing non sticky bag;
5.PLC+ LCD touch screen control operation, can easily touch the device parameters on the touch screen, production and error information clear and intuitive;
6. numbers show temperature control;
7. electric and pneumatic components are selected by international famous brands.
Specification
| Capacity | 5000-6000pcs/h |
| Working Voltage | AC 220V-380V(choose) |
| Accuracy | ±0.5~1% |
| Filling Head | 4 heads (each head can work alone) |
| Working Pressure | 0.6~0.8Mpa |
| Power | 2.2(kw) |
| Sealing Temperature | 120~200ºC(Adjustable) |
| Bag Open Way | Sucker Automatic Open |
| Mask Size | W90-170 H110/230 |
| Size | L1700*W1000*H1700(mm) |
Products Show
High speed automatic facial mask filling sealing machine
1.automatic bag feeding,liquid filling,sealing,printing and bag out feeding.
2.All contact parts are made from Stainless steel 316,complying with GMP requirements.
3.Variable filling machine can be chosen for different filling material.
4.No bag,no fill,no bag,no seal.
5.PLC combined with touch screen control system,parameters and operation can be done in the panel.Production output and the error message can be easily seen from the screen.
6.Digital temperature controllers.
7.selected electronic and pneumatic components from reliable international manufactures.
