High Speed Homogenizer / Cosmetic Making Machine Powerful Easy To Operate Durable
Pharmaceutical / Cosmetic Making Machine Powerful Easy To Operate Durable
Product Application of the Pharmaceutical / Cosmetic Making Machine
Vacuum paste machine is widely used in toothpaste, cosmetics, food, chemical industry viscous paste manufacturing. It is the development by our company on the basis of absorbing and digesting the Swiss VME type and the German become ix-rw type and outer circulation. The complete set of equipment is equippede with a coagulation pot, pre-mixing pot, gule pot, power pot, colloid pump, operating platform, vacuum system process and grinding, mixing, vacuum system of three cream is accomplished in a paste pot, signufucantly reduce the material loss, reduce the pollution of the paste, improved the production efficiency and clean.
The working principle of the machine is according to the production process will be a variety of raw material in turn into the paste machine, all kinds of raw maerials by strong mixing, kneading, grinding make full dispersion and mixing evenly. the vacuum degassing into a paste.
Product Description of the Pharmaceutical / Cosmetic Making Machine
| Mixing speed | variable speed 0~63rpm |
| Homogenizing speed | variable speed 0~3500rpm |
| Motor brand | SIEMENS/ABB |
| Converter | SIEMENS/Mitsubishi/Delta |
| Temperature controller | Omron/CHNT/Delixi/etc |
| Control type | PLC/Electric button manual |
| Material | Stainless steel 316/304/304 |
| Heating method | Electric heating/Steam heating |
| Cooling method | Tap water/Chiller water |
| Capacity | 5~5000L(Custom designed) |
| Application | Cosmetics cream /lotion / gel / shampoo / liquid soap /detergent / mayonnaise / ketchup /etc |
| Cover type | Opened/Un-opened |
| Discharge type | Bottom discharge |
Features of the Pharmaceutical / Cosmetic Making Machine
*The ointment is operated in a sealed container and operated in a vacuum state. The material is sucked through the botto, of the pot to ensure that no dust flies in the production process.
*Screper mixing system using active scraper, when stirring the material, the material scraping, so that the temperature transmission uniform, so that the material does not produce accumulation and dead ends.
*Rapid mixing in a solution tray with a diameter of 300mm or 350mm, throught the high-speed roation of power and liquid material mixture, and in the system produced a flip pot.
*There are two options for high speed homogenizer or colloid mill. Homogenizer placed in the bottom of system, the shaft is very short, will not produce jitter, the material from the bottom of system, the shaft is very short , will not produce jitter, the material from the bottom of the pot, through the homogenizer into the pot back to the pot outside the pipeline, and then from the top of the pot back to the liquid for external circulation, fully guarantee that akk materials, have equal opportunities to flow homogenizer, at the material pump. Colloid by nylon screw propeller material into the colloid mill up, grinding the boby is a pair of tapered helical discs, the material can be polisged here, the gap between the adjustable.
*Vacuum pump with two-stage vacuum pump, and equipped with atmospheric ejector, to ensure high vacuum.
*The use of one-step process, in the paste machine to complete all the paste operation, significantly reducing mayerial loss.
*The supporting raw material conveying system, automatic measurement and control system, through PLC operation to achieve paste atomation.
