Lotion Mixer Machine 1000L 316L Stainless Steel Vacuum Emulsifier For Hand Cream
Lotion Mixer Machine 1000L 316L Stainless Steel Vacuum Emulsifier For Hand Cream
Definition of the vacuum emulsifier:
This means that when the material is under vacuum, it will use high shear emulsifier to quickly and uniformly distribute one or more phases to another continuous phase. The powerful kinetic energy generated by the mechanical effect will process the material in the narrow space between the stator and the rotor. Through more than 100,000 times per minute of hydraulic shearing, centrifugal extrusion, impact, crushing and turbulent operation, the material will be uniformly dispersed and emulsified immediately. After the high-frequency reciprocating cycle, stable, high-quality, and fine finished products without bubbles will be obtained.
Specification of the Vacuum Emulsifier:
| specification | working volume(L) | heating method (optional) | diamension (L*W*H)(M) | Weight(KG) |
| QHE-50 | 50 | Electic heating or steam heating | 2.6*2.4*2 | 650 |
| QHE-100 | 100 | Electic heating or steam heating | 2.8*2.5*2.2 | 850 |
| QHE-200 | 200 | Electic heating or steam heating | 3*2.8*2.3 | 1100 |
| QHE-500 | 500 | Electic heating or steam heating | 3.3*3*2.5 | 1500 |
| QHE-1000 | 1000 | Electic heating or steam heating | 4.2*3.5*3.8 | 2500 |
The vacuum emulsification mixer is mainly composed of water pot, oil pot, emulsification pot, vacuum system, lifting system (optional), electric control system (PLC optional), operating platform, etc.
Type stirring blade were left to right:
single way mixing internal & external circulation, double way mixing internal & external circulation, single way mixing & internal circulation, double way mixing & internal circulation, single way mixing & external homogenizer, double way mixing & external homogenizer
Application areas of the Vacuum Emulsifier:
The product is mainly used in daily chemical health products, biopharmaceuticals, food, paint and ink, nanomaterials, petrochemicals, printing and dyeing auxiliaries, pulp, paper, pesticides, fertilizers, plastics, rubber, electrical and electronic industries. In materials with high base viscosity and high solid content, emulsification is more prominent.
Feature of the Vacuum Emulsifier:
1. high sanitary standard manufacturing
2. internal surface mirror polished
3. agitation group consisting of two slow agitators and one fast agitator
4. double speed slow agitators(stepless speed variation as optional)
5. double speed fast agitators(stepless speed variation as optional)
6. mechanical seal of agitation groups
7. lifting cover system
8. tilting vessel
9. body and agitators made of SS AISI 316L
10. internal pressurization for discharge and inertization
11. SS AISI 304jacket
12. cover for thermal insulation made of SS tank in tank13.vacuum group
14. heating station
15. sterilizing filter installed on the vacuum-breaking device
16. cleaning balls
17. embedded CIP group
18. product temperature check by means of Pt 100 probe,special sheath ,close to the side
19. buttons or PLC controlled process functions
20. electronic weighing system.
