Salad Dressing Mayonnaise Making Machine Vacuum Homogenizing Emulsifier
Salad Dressing Homogenizer Emulsifier Production Equipment Mayonnaise Making Machine
Application areas of the Vacuum Emulsifying Homogenizing Machine
The product is mainly used in daily chemical health products, biopharmaceuticals, food, paint and ink, skin care, printing and dyeing additives, pulp, paper, pesticides, fertilizers, plastics, rubber, beauty and other industries. In materials with high base viscosity and high solid content, emulsification is more prominent.
Main components of the Vacuum Mixer Homogenizer
The vacuum emulsification mixer is mainly composed of water pot, oil pot, emulsification pot, vacuum system, lifting system (optional), electric control system (PLC optional), operating platform, etc.
-
Frame mixer
Dead-end stirring with sufficient mixing area and good stirring effect.
-
High shear homogenizer
Fast agitator: teethed type rotor and stater assembly installed on the vessel. Bottom or on the top as optional items, several interchangeable configurations ate available.
-
Hydraulic lifting system
Used for material discharge and cleaning. It is more convenient and safer for the operator.
-
Pharmaceutical grade material
High quality SUS304 & 316 material, internal and external mirror polish of homogenized tank.
Specification of the Vacuum Mixer Homogenizer
|
PN |
100L vacuum emulsifying mixer |
||
|
Capacity |
Design volume: 100L, working capacity:100L |
||
|
Kettle Cover |
Liquid(particle)inlet, sunk material inlet, air inlet with filter, inspect light and sight glass, vacuum port, pressure meter(1 to -0.1 bar), pressure clamp |
||
|
Mixing pot
|
Material
|
Inner layer: SUS316L thickness: 4mm |
|
|
Middle layer: SUS304 thickness: 4mm |
|||
|
Outside layer: SUS304 thickness:3mm |
|||
|
configuration
|
Bottom material exhaust, size: 1.5” |
||
|
Temp. sensor (0-199℃) |
|||
|
Electrical heating: 8kw, cooling water inlet |
|||
|
Stirring system |
Homogenizer |
1．Material: SUS316L; standard homogenizer |
|
|
Stirring scrap and middle stirring |
Material: SUS316L,Scrap material: PTFE |
||
|
1. Stirring scrap and middle stirring use the same motor |
|||
|
Safety: 1. During stirring, the cover can not open, 2. Cover lift can not stirring. |
|||
|
Vacuum system |
1. Vacuum pump: water recycle, power 1.5kw/380V/50Hz |
||
|
Heating method |
Jacket electrical heating |
||
|
Exhaust method |
Electric doom and bottom discharge or positive pressure discharge material |
||
|
Pressure |
Pressure in the pot during working: -0.090 Mpa; Jacket working pressure:0.2 Mpa |
||
|
Control box |
SUS304 , 1.2mm thickness |
||
|
Dimension |
1900mm×600mm×2650~3500 mm |
||
|
|
Shelf is SS, platform with raised platform and SS guardrail |
||
|
Spare parts |
One year spare parts and tools |
||
|
Guarantee |
One year |
||
|
Using life |
More than 15 years |
||
Features of the Vacuum Mixer Homogenizer
2. Polytetrafluroethylene scraping board cater to body of blending groove and scrape out viscosity material on boiler wall;
3. Homogenizer is installed on boiler bottom to increase motor power more thoroughly and strongly. During fewproduction, it can exert homogenizing effect fully;
4. Mightiness balance isotactic curve rotor is matched with stator with corresponding structure to realize liquid high -capability cut,rubbing,centrifugal to make sure exquisite and slick cream; boiler body and pipe surface mirror polishing 300EMSH (sanitation grade) accords with Daily Chemical and GMP regulation.
5. Homogenizing vacuum emulsifier mixer can choose frequency conversion timing homogenizer and highest rotate speed is 4500 r/min
