China 50HZ Lotion Making Machine Cosmetics Production Line Vacuum Emulsifier for sale

50HZ Lotion Making Machine Cosmetics Production Line Vacuum Emulsifier

Price Negotiable

Price: Negotiation

MOQ: 1 set

Delivery Time: 2-3 weeks

Brand: Qihang

Product Description

Cheap Price for Sale Lotion Manufacturing Machinery Cosmetics Production Line Vacuum Emulsifier

Vacuum Emulsifier Introduction

The vacuum emulsifying mixer is mainly composed of water pot, oil pot, emulsifying pot, vacuum system, lifting system (optional), control system (PLC is optional), operation platform.
It is suitable for production of ointment and cream products in cosmetic and pharmaceutical plants.
The emulsifying effect is more prominent for materials of high base viscosity and high solid content.

Specification of the Vacuum Emulsifier
Main Boiler	Water Boiler	Oil Boiler	Scraping	Homogenizer	Power of Water and Oil Boiler	Hydraulic Lifting	Tilting System	Vacuum Pump Power
L	L	L	KW	KW	KW	KW	KW	KW
5			0.18	0.75		0.75		0.4
10	8	5	0.18	1.1	0.18	0.75		0.4
20	18	10	0.37	1.5	0.18	0.37		0.75
50	40	25	0.75	2.2	0.18	0.37	0.37	1.5
100	80	50	1.5	4	0.75	0.75	0.75	1.5
200	170	100	2.2-3	5.5	1.5	1.5	0.75	2.2
300	250	150	2.2-4	5.5	2.2	1.5	0.75	2.2
500	420	250	5.5-7.5	7.5	2.2	2.2	1.1	3
1000	800	500	7.5-11	11	4	2.2-4	1.5	4
2000	1600	1000	11	18.5	5.5	4	1.5	7.5

Structure Characteristics of the Vacuum Emulsifier

* Sufficient emulsification for the high adherence (over 5000 C.P.S.)
* The diameter of the emulsified grain can reach 2-5μm.
* Adopt high frequency vacuum material sucking device, convenient to operate.
* Made of stainless steel, healthful and axenic in operation.
* Easy to clean.
* The newest shearing and cutting homogenizing machine of non-clearance ceramic can make the diameter of the emulsified material reach 0.5μm.

* The machine is provided with vacuum, hydraulic pressure, heating, cooling and other functions.
