Specification of the Vacuum Homogenizer Emulsifier

Model

Effective

Emulsifying Motor

Agitator

Vacuum pump

electirc Heating power/kw

Steam heating pressure /Mpa

Capcity/L

KW

RPM

KW

RPM

KW

Limit Vacuum

QHE-5L

5

0.55

0-3600

0.4

0-65

0.37

-0.1

6

0.2

QGE-10L

10

1.1

0-3600

0.55

0-65

0.37

-0.1

6

0.2

QHE-20L

20

1.5

0-3600

0.55

0-65

0.37

-0.1

9

0.2

QHE-50L

50

3

0-3600

0.75

0-65

0.75

-0.1

12

0.2

QHE-100L

100

4

0-3600

1.5

0-65

1.5

-0.1

24

0.2

QHE-200L

200

5.5

0-3600

1.5

0-65

2.2

-0.1

28

0.2

QHE-300L

300

7.5

0-3600

3

0-65

2.2

-0.1

32

0.2

QHE-500L

500

11

0-3600

4

0-65

4

-0.1

50

0.2

QHE-1000L

1000

15

0-3600

5.5

0-65

4

-0.1

54

0.2

QHE-2000L

2000

18.5

0-3600

7.5

0-65

5.5

-0.1

recommend steam hetaing

0.2

QHE-5000L

5000

22.5

0-3600

15

0-65

7.5

-0.1

0.2

The parameters for reference ONLY, all the machines can be customized accordingly.

1. High-efficiency homogenizer:

It adopts Germany combined six-layers shearing teeth structure, which gets dozens of times of emulsification effect every time the homogenizer shears the material.
2. Going up & down type homogenizing emulsifier:

Suitable to mix many kinds of materials. Without dead corner, leaving no materials in the tank after discharge. Homogenizer can work long time continuously. It is the best emulsifier ever.
3. Material suction and discharge function:

It can be fed materials from up side and down side, or separately. Long-distance conveying function, to avoid the final products being polluted.

• Pot Lid Process: Electronic vacuum pressure gauge, vacuum exhaust valve, vacuum port, positive pressure air inlet, cleaning ball.
• Water and oil pot: Top eccentric installation, the disperion motor power is 1.1KW.
• The dispersion variable is 1450rpm.
• Inner polishing is above 300MESH level.
• Jacket electric heating Design pressure: 0.3Mpa
• Working pressure: 0.20Mpa
• Stirring is high-speed dispersion (or paddle stirring).
