Specification of the Vacuum Homogenizer Emulsifier

Model

Capacity

(L)

Mixing power

(kw)

Mixing speed(r/min)

Homogenizing power(kw)

Homogenizing speed(r/min)

Heating method

QHE-20

20

0.37

0-63

0.75

0-3000

Steam heating or electric heating(optional)

QHE-50

50

0.37

0-63

2.2

0-3000

QHE-100

100

1.5

0-63

3

0-3000

QHE-150

150

1.5

0-63

3

0-3000

QHE-200

200

1.5

0-63

4

0-3000

QHE-350

350

2.2

0-63

4

0-3000

QHE-500

500

2.2

0-63

5.5

0-3000

QHE-1000

1000

5.5

0-63

9

0-3000

QHE-2000

2000

5.5

0-63

11

0-3000

Note: In case of inconformity of the data in the table due to technical

improvement or customization, the real object shallprevail.

1. QIHANG Fixed type internal and external Emulsifier Homogenizer Mixer for Cosmetic Manufacturing, which can meet different technological demands.
2. The homogenizing structure is made through German techology. The machine adopts the improted double-end mechanical seal effect. The maximum emulsifying rotation speed can reach 3500rpm and the high shearing fineness can reach 0.2-5um.
3. The vacuum defoaming can make the materials meet the requirement of being aseptic. The vacuum materials vacuum sucking can avoid dust.
4. The main boiler lid can adopt lifting system, it is easy to clean and the cleaning effect is more obvious, the main boiler can adopt tilting discharge.

1. Various forms of blending vanes are suitable for production of different types of production of products.
2. The wall scraping mixer adopts frequency converter to adjust the mixing speed, suitable for various products based on clients' requirements.
3. The mixing system includes single-way mixing, double-way mixing and helical ribbon mixing. The lifting systems include single-cylinder lifting and double-cylinder lifting. According to your request, we can customized the suitable machine for you.
4. Vacuum defoaming can make the material reach requirement of aseptic. It adopts the vacuum to suck the material especially for the powder material, which can avoid the dust.
