3KW Short Circuits Protection Open Frame diesel inverter generator
Portable Diesel General
Basic Parameters
| Model 型号 | GD3700T | GD6700T | GD7700T | GD8700T | GD9700T |
| Rated frequency (Hz) | |||||
| Rated output(kW) | 2.5 2.8 | 4.5 5.0 | 5.0 5.2 | 6.0 6.2 | 6.3 6.5 |
| Max. output (kW) | 2.7 3.0 | 5.0 5.5 | 5.5 5.7 | 6.5 6.7 | 6.8 7.0 |
| Rated voltage (V) | 220 or as request | ||||
| Rated currency (A) | 11.3 12.7 | 20.4 22.7 | 22.7 23.6 | 27.3 28.2 | 28.6 29.5 |
| Rated rotation speed (r/min) | 3000 3600 | ||||
| Phase NO. | Single phase/ | ||||
| Power factor(Cos Φ) | 1 | ||||
| Insulation Grade | F | ||||
| Pole number | 2 | ||||
| Excitation mode | Self-excitation & constant voltage (AVR) | ||||
| Panel Type | General Panel | ||||
| Receptacle | Two receptacles | ||||
| Connection pole | Without | ||||
| DC12V output | Connection pole output | ||||
| Overall dimension(L×W×H)(mm) | 930×530×740 | 930×530×740 | 930×530×740 | 930×530×740 | 930×530×740 |
| Dry weight (kg) | 164 | 170 | 171 | 171 | 172 |
| Working assorting weight(kg) | 179 | 185 | 186 | 186 | 187 |
| Noise level(7m)[d B(A)] | 72 | 72 | 72 | 72 | 72 |
| Structure type | Silent type | ||||
| Engine Model | YM178F | YM186FA | YM188F | YM192F | YM195F |
| Engine Type | Single cylinder, vertical, four-stroke, direct injection | ||||
| Cylinder NO.-bore×stroke(mm) | 1-78×62 | 1-86×72 | 1-88×75 | 1-92×75 | 1-95×75 |
| Displacement总排量(ml) | 296 | 418 | 456 | 498 | 531 |
| Rated power [kW(r/min)] | 3.68/3000 4/3600 | 5.7/3000 6.3/3600 | 6.5/3000 7.2/3600 | 7.6/3000 8.2/3600 | 8.1/3000 8.7/3600 |
| Compression ratio | 20:01 | 19:01 | 19:01 | 19:01 | 19:01 |
| Lubrication system | Pressure splashed | ||||
| Starting system | Recoil + Electric Start | ||||
| Fuel type | 0＃(summer)-10＃(winter)-35＃(chillness)diesel 0＃ | ||||
| Lube oil brand | CD grade or SAE10W-30,15W-40 | ||||
| Lube capacity(L) | 1.1 | 1.65 | 1.65 | 1.65 | 1.65 |
| Starting motor capacity (V-kW) | 12V 0.9kW | 12V 0.9kW | 12V 0.9kW | 12V 1.2kW | 12V 1.2kW |
| Charging generator capacity (V-A) | 12V 8.3A | 12V 8.3A | 12V 8.3A | 12V 8.3A | 12V 8.3A |
| Battery capacity(v-Ah) | 12V 30Ah | ||||
| Fuel consumption (glkw*h) | ≤280 | ≤280 | ≤280 | ≤280 | ≤280 |
| Fuel tank capacity(L) | 15 | 15 | 15 | 15 | 15 |
| Continuous running time(hr) | 11 | 7.5 | 6.5 | 5.5 | 5 |
Product Features:
Low Noise Running
Scientific damping effect, advanced air-flue design and muffler device.
Strong power
Four-stoke diesel engine, new tip-clearance fuel pump and bottom inertia injection technology, makes burning full and power strong.
Low oil level alarming system
New AVR (Automatic Voltage Regular) provide Overload protection
Short circuits protection
High conversion efficiency
class F insulation, high conversion efficiency, smart AVR controller ensures stable voltage and less voltage waveform distortion
100% copper alternator with advanced winding & provide a stable output while running inductive loads
Preheating device
With air-preheating device, it can be easily started at low temperature.
Optional items
Remote control, more control distance and control as your kindly heart.
Remoter: control anytime anywhere freely.
ATS Control to make the city power and generator change more easy.
ATS: automatic transfer from city power and gen-set power.
It can be used Smart digital panel to make the generator more easy and safe using.
Intelligent digital control panel: with overload, over voltage, over current and low oil pressure protection function.
