40 Inch 8mm Multi Screen Video Wall For Indoor Wall Mount Type High Brightness

Price Negotiable
Price: Negotiable
MOQ: 1PCS
Delivery Time: 5-15 days after payment
Brand: Topview
Product Description

40 inch 8mm wall mount multi screen video wall indoor lcd video wall screen



Product Description



1.Full HD panel with 1920*1080P solution;
2.with image processor and matrix can support multiple-limited diplay unit;
3.can choose any number of splicing,combination of the screen(M*N);
4.VGA/DVI/BNC video interface terminal,can connect the computer and all kinds of video equipment



roduct Name
40-Inch splicing unit
Product Number
CV-S-40-SX-080
Screen Size
40-inch
Unit Size(mm)
891.5*497.5*47.5
Bilateral Combined Seam(mm)
8MM
Panel Type
TFT-LCD
Zoom
16:09
Best Resolution
1920×1080
Color Gamut Color Temperature
92% 10000K
Brightness
500cd/m²
Weight
13KG
Contrast
`5000:1
Operating Temperature
0~60℃
Response Time
8ms
Working Humidity
20~80℃
Dot Pitch
0.1765×0.530mm
Power Supply
100~240V,50/60HZ
Viewing Angle
178°/178°
Service Life
60000H
Display Color
8BIT,16.7m
Rated Power Consumption
180W (Up to 300W)
Input Interface
VGA*1,HDMI*1,DVI*1,BNC*2,ISP*1,RS232*1
Output Interface
Control Output RS232*2
Operation Method
RS232 centralized control, network remote control
Support Format
NTSC,PAL,480I,480P,720P,1080I
Basic Skills
The same unit can display any one of the three types of input signals, the signal type is optional: RGB, VIDEO and component video
Continuous Working Time
24 hours a day, 7 days a week
Installation Method (optional)
Wall-mounted, embedded wall-mounted, floor cabinet type, floor stand type



Advantages of LCD Video Wall


1, Reliable quality and low maintenance: Less thermal diffusivity makes the components and parts more stable.
2,High Definition and clear image: High brightness and contrast make colors brilliant and bright, as well as stable and clear image.
3, Wide viewing angle: DID LCD panel makes the viewing angle up to 180°.
4, Low power consumption and low heat radiation
5, Long service life lowers the cost of usage and maintenance
6, Innovative and advanced: 42” to 60” Ultra thin bezel LCD video wall, the thinnest bezel up to 1.8mm
7, Ultathin and lightweighted: The ultra thin and lightweighted design makes it easy to transport and install.
8, Economic al and practical: High performance and high quality make it cost less.



















FAQ:
Q:How long is the warranty time for your products?
A: Our officially promised warranty time is one whole year after delivery at best.
Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days or depend on the size and quantities of your order.
Q:what brand of screen are you using?
A:we are using Samsung,LG and AUO screen.
Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
Q:Do you give any discount ?
A: We are Manufacturer, so we are able to give you the best price and best service at the same time.
Q:What payment methods your company accept?
A:We accept most of the payment methods,but mainly accept T/T, WesternUnion,Paypal and MoneyGram
