25 Tons Excavator Mounted Vibro Hammer For PC250 R250 SY250

Price Negotiable

Price: $20000-32000/pcs

MOQ: 1 Pcs

Delivery Time: 8-16 workdays

Brand: Huitong

Product Description

25 Tons Excavator Mounted Vibratory Hammer V250 Hammer For PC250 R250 SY250

Production Descrption

Huitong Excavator mounted vibratory hammer can be applied for a wide range of working enviroment because of its small size and simple operation procedure, such as drainage maintenance, river-bank maintenance and marshland working wherever onshore and offshore piling job.

High frequency hydraulic vibratory pile driver internally installed two eccentric shaft. It adopts hydraulic motor to drive and produce high-speed revolution and vertical vibration force. Through the damping rubber block to maintain a certain amplitude to cope with various types of soil and pile driving. Sheet Pile Vibro Hammer can be applied for a wide range of working enviroment because of its small size and simple operation procedure, such as drainage maintenance, river-bank maintenance and marshland working wherever onshore and offshore piling job.

Features:

can be installed on all kinds of excavators and make efficient, flexible and accurate pile driving in many sites.

Suitable for different site and soil conditions

Suitable for a wide range of piles including sheet piles, H-beams, tubular steel piles, timber piles, pre-concrete piles

Huitong Excavator Vibro Hammer
Model	V250	V300
Eccentric moment (Nm)	40	85
Amplitude (mm)	6.8	14
Oil Flow (L/min)	155~200	200~255
Pressure (kg/cm2)	240~260	240`260
Frequency (rpm)	2800	2800
Max. Centrigufal Force (kN)	300	570
Max. rotation angle	360 degrees	360 degrees
Vibro hammer with clamp (LxWxH) (mm)	1300x1400x1400	1500x1550x1700
Vice arm (LxWxH) (mm)	2600x650x1050	3200x650x1150
Total Packaging Volume	6.97m3	9.28m3
Net Weight of Vibro Hammer( kg)	2000	2800
Net Weight of Vice arm (kg)	500	650
Total net weight (kg)	2500	3450
Matched Excavator (Ton)	20~35	35~50
