ZYMC-700S PLANETARY MIXER
The planetary centrifugal mixer is designed for mixing and deaerating various kinds of liquid, slurry, paste, and powder materials. It could be used for mixing and homogenizing nanopowders, nanotubes, ceramics powders, battery powder/slurry, metal powders, and especially high viscosity slurry/paste. The vacuum mixing capability is integrated for best mixing results.
| SPECIFICATION FOR ZYMC-700S PLANETARY MIXER | |||
| Container Capacity | 700ml*2cups | Working Capacity | 350ml*2cups |
| Revolution Speed | 130-2000RPM | Rotation Speed | Adjustable |
| Protection | Door cover, Vibration, Over load | Operation Type | Human-machine Interaction Mode |
| Multi-parameter Group | 0-5group, 3part/group | Power/Voltage | 1.5KW/220V |
| Size | L730*W510*H700mm | N.W. | 120KG |
Main Features:
・Single/double cups
・Multi-step parameter
・Various adapters, customizable
・Suitable for research and development, volume production
・Unlimited scale of revolution and rotation, wide range applicable scope
・Original defoaming mode is available as standard
・Dedicated stand with the built-in vacuum pump enables to save the footprint
・Ease of condition set on the touch panel
・Adapters for various containers are available
Original defoaming mode is available as standard, it is possible to defoam materials containing organic solvents that are not suitable for vacuum function. The rotation / revolution ratio is optimized, making it easy to optimize the recipe when scaling up from a small machine.
Principle of Operation:
Revolution: the carrier revolves inside the cavity with the speed of 0-2000RPM around the central axis. In effects of the generated centrifugal force, the material inside the carrier moves along the vector direction, pressed down, so the air bubbles are separated.
About US
ZYE is a leading precision equipment manufacturer focusing on planetary mixing and high-end three-roll-mill in China,and is a national high-tech enterprise as well.
We are committed to providing the best solution of mixing, degassing and grinding solution for every segment of material field.
PACKAGE:
1 Standard exported package: Internal anticollision protection, external export wooden box packaging.
2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.
3 Responsible for the damage during the shipping process, will change the damaged part for you for free.
