CNT Nanometer Composite Planetary Centrifugal Mixer 0-8 Recipes 11.5KW
CNT Nanometer Composite Mixer 0-8 Recipes Parameter Can Be Set
Application
The planetary centrifugal vacuum mixer ZYMC-10080HV is designed for mixing and deaerating various kinds of liquid, slurry, paste, and powder materials. It could be used for mixing and homogenizing nanopowders, nanotubes, ceramics powders, battery powder/slurry, metal powders, and especially high viscosity slurry/paste. The vacuum mixing capability is integrated for the best mixing results
・Maximum of 10kg of material can be simultaneously mixed and deaerated
・By means of the variable rotation/revolution ratio mechanism, parameter settings in accordance with material properties are achieved
・Supports processing at non-vacuum, enabling processing of materials with volatile components
・No overflow of materials during operation
・By using adapters, achieves processing with various containers
Product specification
| SPECIFICATION FOR ZYMC-10080HV PLANETARY MIXER | |||
| Container Capacity | 11000ml | Working Capacity | 10000g |
| Revolution Speed | 100-750RPM | Rotation Speed | Invariablenes |
| Protection | Door cover, Vibration, Over load | Operation Type | Touch screen |
| Multi-parameter | 0-8 recipes, 5parts/ recipes | Power/Voltage | AC380V;11.5KW |
| Dimension | L1750*W1120*H1080mm | N.W. | 850KG |
Comparison of the mixing:
