1.5KW Planetary Centrifugal Vacuum Mixer 350ml 2000RPM For Laboratory
1.5KW 350ml 2000RPM Planetary Centrifugal Vacuum Mixer for Laboratory
About US
ZYE is a leading precision equipment manufacturer focusing on planetary mixing and high-end three-roll-mill in China,and is a national high-tech enterprise as well.
We are committed to providing the best solution of mixing, degassing and grinding solution for every segment of material field.
Product specification
| Equipment model | ZYMC-200V |
| Container Capacity | 350ml*1(Cup) |
| Operation Type | Human-machine Interaction Mode |
| Revolution Speed | 130-2000RPM |
| Rotation Speed | Invariablenes |
| Vacuum | 80/Minute,APROX.-100KPa |
| Protection | Door Cover,Breakdown, Overload |
| Dimension(mm) | L585*W405*H600mm |
| Voltage | 0.8-1.5KW, 220V |
| Weight | 80KG |
| Power Supply | 220V.50Hz |
| Clamp | Option |
Introduction
The planetary centrifugal vacuum mixer is designed for mixing and deaerating various kinds of liquid, slurry, paste, and powder materials. It could be used for mixing and homogenizing nanopowders, nanotubes, ceramics powders, battery powder/slurry, metal powders, and especially high viscosity slurry/paste. The vacuum mixing capability is integrated for best mixing results. The standard package includes containers and counter-weights.
How to use and maintain the ink mixer
1. When using, fix the selected stirring blade and the rotating shaft
2. Loosen the fixed handle on the motor base, lift the motor to adjust the position, adjust the height of the speed shaft and the container, then tighten the motor base and container, put in the material and cover the container cover.
3. Adjust the speed control knob to the zero position, turn on the power switch, and then adjust the speed to the required speed.
4. It is not advisable to drive an empty car when the speed is greater than 4000 rpm.
5. After use, it should be cleaned to maintain the cleanliness of the machine.
FAQ
1.Which procedure to secure your Quality?
Our company has own research & development and production base, the products will be profassionally tested before loading to ensure the accuracy of test results and authority.
2.How about your company product after-sales service system?
Product after-sale guarantee period is 12 months. And our professional pre-sales and after-sales department can reply you within 24 hours for any technical problems.
3.How about customers evaluation for your products?
Our services get the trust of the customer satisfaction and recognition for themselves.
