700ml Planetary Vacuum Mixer Deaeration Centrifugal Mixing Machine Single / Double Cups
Planetary vacuum mixer Deaeration mixer Single and double cups optional
ZYMC-700VS Main feature
1. Double cups
2. Vacuum is included
3. Multi-step parameter
4. Various adapters, customizable
5. Suitable for research and development, volume production
6. Unlimited scale of revolution and rotation, wide range applicable scope
7. Vacuum: 80L/min, approx.-100kpa (when the altitude is zero metres)
8. Standard accessories:Cup:6pcs；Transmission belt:1 pcs(backup)
Product specification
| SPECIFICATION FOR ZYMC-700VS PLANETARY MIXER | |
| Container Capacity | 700ml*2cups |
| Revolution Speed | 130-2000RPM |
| Protection | Door cover, Vibration, Over load,Vacuum leak |
| Multi-parameter Group | 0-5 recipes, 3part/recipes |
| Size | L730*W510*H700mm |
| Working Capacity | 350ml*2cups |
| Rotation Speed | Adjustable |
| Operation Type | Human-machine Interaction Mode |
| Power/Voltage | 1-1.5KW/220V |
| N.W. | 125KG |
Application
Our planetary mixer is widely used for semiconductor, touch screen, LED, photovoltaic, new materials and chemistry industry.
Like Epoxy Resin, Adhesive Agent, Silver Paste, Soldering Paste, LED Phosphor Material, Carbon Nanotube and so on.
Especially for high viscosity and good fineness products.
Package&Shipping
-Packing: 1 set, wooden box
-Outside package: Standard export wooden
-Inner package: Shock-proof plastic film
