19.32m3 375HP SINOTRUK Tipper Truck With Short Mileage
2014 Year Used SINOTRUCK Tipper Truck With Short Mileage
-1. Main Information For Used SINOTRUCK Tipper Truck.
Used sinotruck tipper truck before shipment will arrange the quality test and send the inspection report, such as the engine test, cargo box lifting test, drive test etc. We will supply the picture and video of quality test to customers. And we also supply 3 month warranty for our TRUCKMAN brand used sinotruck tipper truck.
-2. Main Specification For Used SINOTRUCK Tipper Truck.
| Model | Used SINOTRUCK Tipper Truck |
| Engine | WD615.96E, 375HP |
| Cabin | HW76 cabin, one bed, A/C. |
| Gearbox | HW19710, 10 forward and 2 reverse gear |
| Tire | 12.00R20, 10 pcs |
| Cargo Box | 5600x2300x1450mm, 19.32m3 |
| Loading Tons | 25-30 Tons |
| Fuel Tank Capacity | 300L |
| Max Speed | 75km/h |
| Warranty | 1 year |
| Made Year | 2014 |
| Mileage | 33570km around |
-3. Used SINOTRUCK Tipper Truck Axle Information.
HC16 Axles Detail.
| Model | HC16 |
| Brake Drum | Ф420x185 |
| Input Flange | Ф180 |
| Lubricants (L) | GL5 85W-90 |
| Rated Load | 2x16000 |
HC16 Axles Main Advantage.
-. The structure of the final reducer is optimized, and advanced structures such as bai gear large modulus design, reinforced input shaft, and integrated through shaft are realized.
-. The three-section cast axle housing has an enlarged square section and good supporting rigidity, which improves the service life of the main reducer assembly.
-. It is matched with wide-body brake, with good braking stability and long life of friction plate.
-. The whole bridge has higher rigidity and strength, strong bearing capacity, large transmission torque, high reliability and low noise.
-. It is suitable for harsh environment such as bad road conditions and high impact. It is the best choice for heavy engineering vehicle users.
