Vibrating Stripping Machine, for carton box Flexo Printer Slotter Die-cutter Stacker machine

Vibrator Stripping Machine

Functional Specifications:

1) Collecting arms pneumatic lifting, adjustable individually.

2) Vibrating stripping to clear the cutting scraps, equipped with blower to achieve best stripping function.

3) Equipped with bottom belt to collect waste scraps and output easily.

Automatic Flexo Printer Slotter Die-cutter Stacker

(Lead-edge Feeding, 1~5 colors printing, Computer-control)

Functional Specifications:

1. This machine could do 1~5 colors printing, slotting, edge-cutting, corner-cutting, creasing, die-cutting, stacking, etc. on corrugated cardboard at one process.
2. Adopt vacuum adsorption lead-edge feeding cardboard, accurate and reliable.
3. Adopt cross slider transmission. Adopt spouting style cycle lubricate.
4. The electric appliances of a whole machine adopt the excellent product by the domestic produces. Phase adjustment adopts planet gear structure, digital input.
5. All rollers chrome plated, high grade rubber and anilox roller, print elegant pattern.
6. Adopt pneumatic uplift plate, pneumatic lock close, electric equal ink, pneumatic supply ink, electric separate and retune with pneumatic brakes, etc.
7. Slotting unit computer control combined adjustment for carton box length, width and height.
8. Die-cutting unit equipped with auto moving and repairing device for longer use life.

Technical Parameters:
