China High Flow Capacity Plain Dutch Woven Filter Cloth For Water Treatment for sale

High Flow Capacity Plain Dutch Woven Filter Cloth For Water Treatment

Price Negotiable

Price: Negotiable

MOQ: 5 SQUARE METER

Delivery Time: 7-10 days after get the deposite

Brand: XR

Product Description

High Flow Capacity Plain Dutch Woven Filter Cloth For Water Treatment

ADVANTAGES OF POROMETRIC FILTER MEDIA:

• Increased permeability

• Reduction of highest, local pore velocity

• Good backwashing properties

• High porosity

• High dirt holding capacity

• Good price-performance ratio

• Poresize down to 18 µm

• Seawater restistant down to 20 µm

Characteristics of woven filter mesh

Acid-resisting, alkali-resisting and anti-corrosion.
Hihg strength, good tension toughness and abrasion performance, durable in use.
Resistance to high temperature oxidation.
Highly polished, no need to do any surface treatment, with convient and simple maintenance.

Applications of woven filter mesh

In exreme corrosion environment conditions sieving and filtering.
Seawater desalination equipment.
Petroleum,petrochemical equipment.

Here have Four woven type filter cloth

Woven Filter Cloth Detailed specifications:

1.Plain Weave Filter Mesh/Filter Screen

Mesh	Wire dia	Aperture
Mesh	mm	mm
1x1	2.03	23.37
2X2	1.60	11.10
3X3	1.37	7.09
4X4	1.60	4.75
4X4	1.19	5.16
5X5	1.04	4.04
6X6	.89	3.35
8X8	.71	2.46
10X10	.64	1.91
10X10	.51	2.03
12X12	.584	1.52
12X12	.508	1.60
14X14	.584	1.22
14X14	.508	1.30
16X16	.457	1.13
18X18	.432	.98
20X20	.508	.76
20X20	.406	.86
24X24	.356	.70
30X30	.330	.52
30X30	.305	.54
30X30	.229	.62
35X35	.279	.45
40X40	.254	.38
50X50	.229	.28
50X50	.203	.31
60X60	.191	.23
60X60	.178	.25
70X70	.165	.20
80X80	.165	.15
80X80	.140	.18
90X90	.127	.16
100X100	.114	.14
100X100	.102	.15
100X100	.089	.17
110X110	.1016	.1295
120X120	.0940	.1168
150X150	.0660	.1041
160X160	.0635	.0965
180X180	.0584	.0838
200X200	.0533	.0737
250X250	.0406	.0610
270X270	.0406	.0533
300X300	.0381	.0457
325X325	.0356	.0432
400X400	.0254	.370
500X500	.0254	.0254
635X635	.0203	.0203

2.Plain Dutch Weave Filter Mesh /Filter Screen

Mesh	Wire dia(inch)	Absolute Filtration Rating( μm )	Nominal Filtration Rating( μm )
8X85	.014X.0126	318 - 340	250 - 255
12X64	.024X.0165	270 - 285	200 - 205
14X88	.020X.013	225 - 245	150 - 155
20X150	.0098X.007	155 - 165	100 - 105
24X110	.015X.010	115 - 125	80 - 85
30X150	.009X.007	95 - 100	65 - 70
40X200	.007X.0055	65 - 70	55 - 60
50X250	.0055X.0045	55 - 60	40 - 45
80X400	.0049X.0028	43 - 48	35 - 40

3.Twilled Dutch Weave Filter Mesh /Filter Screen

Mesh	Wire dia(inch)	Absolute Filtration Rating(μm)	Nominal Filtration Rating(μm)
20x250	.0098x.0079	110-120	98-105
30x360	.0098x.0060	90-100	80-84
40x560	.0070x.0040	70-75	47-52
120x400	.0040x.0025	50-55	37-43
120x160	.0040x.0025	40-45	28-32
80x700	.0040x.0030	35-40	24-26
200x600	.0024x.0018	28-32	19-21
165x800	.0028x.0020	24-26	14-16
165x1400	.0028x.0016	16-18	9-11
200x1400	.0028x.0016	12-14	5-6
250x1400	.0022x.0016	11-12	3-4
325x2300	.0015x.0010	8-9	2-3
