Zoological Enclosures Stainless Steel Wire Rope Mesh 4.0mm Rhombus
Zoological Enclosures Srainless Steel Wire Rope Network Cargo Net Woven Rope Mesh Guardrail Ferrule Cable Net
The Zoo Wire Mesh is manufactured in the standard diameters 1.0 mm, 1.5 mm, 1.6mm, 2.0 mm, 3.0 mm and 3.2mm. Mesh width of 25 to 200 mm (or bigger) are possible depending on cable diameter.
Rope Mesh is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316.
Mesh connections (ferrules) are available in highly aesthetic stainless steel for premium applications or where resistance to corrosion is a driving consideration.
Finished diamond mesh style when it is stretched at 60 degree angle ;
Zoo Mesh Enclosure Netting Sheet
|
Hole Size (Opening) |
1.2MM(3/64) (7 x 7 ) |
1.6MM(1/16) (7 x 7 ) |
2.0MM(5/64) (7 x 7 ) |
2.4MM(3/32) (7 x 7 ) |
3.2MM(1/8) (7 x 19 ) |
| 20 x 35mm | F-1235 | ||||
| 25 x 42mm | F-1225 | F-1625 | |||
| 30 x 52mm | F-1230 | F-1630 | F-2030 | ||
| 35 x 60mm | F-1235 | F-1635 | F-2035 | ||
| 38 x 66mm | F-1238 | F-1638 | F-2038 | F-2438 | |
| 40 x 69mm | F-1240 | F-1640 | F-2040 | F-2440 | F-3040 |
| 50 x 86mm | F-1250 | F-1650 | F-2050 | F-2450 | F-3050 |
| 60 x 104mm | F-1260 | F-1660 | F-2060 | F-2460 | F-3060 |
| 70 x 120mm | F-1270 | F-1670 | F-2070 | F-2470 | F-3070 |
| 76 x 131mm | F-1276 | F-1676 | F-2076 | F-2476 | F-3076 |
| 80 x 138mm | F-1280 | F-1680 | F-2080 | F-2480 | F-3080 |
| 90 x 154mm | F-1290 | F-1690 | F-2090 | F-2490 | F-3090 |
| 100 x 173mm | F-12100 | F-16100 | F-20100 | F-24100 | F-30100 |
| 120 x 206mm | F-12120 | F-16120 | F-20120 | F-24120 | F-30120 |
The Zoo wire mesh is rhombus mesh, has excellent flexible performance, virtually indestructible,
most impacting-resistant and breaking resistant force, most resisting rain, snow and hurricane.
Recommended Monkey Enclosure Zoo Wire Mesh:
| Material | Cable Diameter | Hole Size | Normal Break |
| SS304/316/316L | 3/32" (2.4MM) | 2.5" x 2.5" | 920 LBS |
| SS304/316/316L | 3/32" (2.4MM) | 2" x 2" | 920 LBS |
| SS304/316/316L | 5/64" (2.0MM) | 2.5" x 2.5" | 676 LBS |
| SS304/316/316L | 5/64" (2.0MM) | 2" x 2" | 676 LBS |
| SS304/316/316L | 1/8" (3.2MM) | 2" x 2" | 1600 LBS |
| SS304/316/316L | 1/8" (3.2MM) | 3" x 3" | 1600 LBS |
Stainless steel zoo wire is light, robust, and transparent. High-quality stainless steel cables and pressed ferrules are used for the production of the mesh and connected to a load-bearing and flexible structure. The curvature in the opposite direction of the stainless steel cables creates the exceptionally robust characteristics of the mesh can even stand up to heavy loads.
Zoo Wire Mesh Details
| Product Name | Stainelss Steel Zoo Wire Mesh |
| Product Type | X-tend Rope Wire Mesh |
| Material Type | High Grade AISI316 |
| Finished | Ultrasonic Bath , Black Oxide |
| Features | Weather-Resistant , Non-Corroding , Rugged |
X-tend Zoo Mesh is custom manufactured to in widths and lengths to suit your zoo park architectural application. Diagonal and irregular shapes can also be supplied. Black anodised or galvanised finish options
The Yuntong Zoo Wire Mesh is a vibrant, premium-quality product made from the stainless AISI 316 material group:the mesh aperature W x H (variable from very tight to very wide), the wire-rope diameter (1.2 mm, 1.5 mm, 2.0 mm and 3.0 mm) determine fucntion and aesthetics.
Characteristics
Custom-Manufactured
Discrete, elegant and flexible.
Multifunctional,and compatible with creative architecture.
Premium Quality, Rugged , Weather-Resistant , Non-Corroding and Corrosion-resistant,Alkali Resistant
