SCR Controlled 523 622 Ternary Positive Air Roller New Energy Kiln
Price:
Negotiable
MOQ:
1 Set
Delivery Time:
Negotiable
Brand:
Yan Yang Tian
Product Description
SCR Controlled 523, 622 And Other Ternary Positive Air Roller Kiln
1, Product Overview
Sintering of ternary positive electrode powder materials such as 523 and 622.
2, Parameter attribute table
| The main technical parameters | |
| Chamber size |
40500mm(L)×1500mm(W)×230mm(H) |
| Power |
800KW/380V |
| Operating temperature |
950℃ |
| Temperature uniformity | ± 5 ℃ (constant temperature zone) |
| Heating temperature zone | 23 groups, 46 points, up and down temperature control |
| Heating element | Equal diameter silicon carbon rod |
| Control method | SCR control, intelligent instrument PID continuous adjustment, PLC + touch screen automatic monitoring |
| Conveying method | Frequency conversion motor + reducer + helical gear + roller bar |
| Chamber atmosphere | Air + oxygen |
| Annual output |
680 tons |
If you have any special sintering process, please contact us, we will customize it for you!
