High Temperature Resistance FKM Rubber Extrusion Products
High temperature resistance white fluoro rubber FKM extrusion or customized rope
Color: White or other light colors. Red rope, Green cord can be customized too.
Material: Fluoroelastomer
Working temperture: -20 degree to 250 degree
Size: 1mm-30mm, length is not limited but should be easy packing.
Feature: High temperature resistance, oil resistance, chemical resistance, acid and alkali resistance, oxidizing agent resistance, steam resistance, aging resistance, inflaming retarding property.
Application: Mechanical sealing, fluid sealing ( strong acid and alkali, steam, hot air, high temperature oil)
Processing method: Extrusion
Description: White color FPM is very much easy to be polluted. This product is made by extrusion that make smooth surface with small tolerance. Good typical property is one advantage as machinery sealing material. We company have ability to design the extrusion formula that make sure easy operate in processing with different sizes and shapes. In machinery industry high temperature and high pressure are common working condition fluoroelastomer is most suitable material.
Typical data sheet:
|
Product Name
|
FKM Rope |
||||
|
Production Time
|
43669 |
||||
|
Post cure condition
|
230℃@24h |
||||
|
Property test
|
|||||
|
Test Item
|
Test Result |
Standard |
|||
|
Hardness, Shore A
|
78 |
GB/T 531.1-2008 |
|||
|
Tensile Strength,Mpa
|
10.4 |
GB/T 528-2009 |
|||
|
Elongation at break, %
|
183.86 |
/ |
|||
|
Test Item
|
Nominal Dimension |
Tolerance Range |
Inspection result,mm |
Quantity,m |
Standard |
|
Diameter,mm |
Φ25 |
±0.8 |
Φ24.8-Φ25.13 |
100 |
GB/T3672.1-2002
|
Product show:
