0.5mm-20mm thickness Fluorine Rubber FKM Sheeting Black
Chemical resistance high tensile strength FKM A type fluorine rubber sheet
Advantages of fluororubber: Excellent high temperature resistance,
operating temperature -20-+250 degrees Celsius; oil resistance to various oils such as
high temperature fuel oil/sulfur lubricating oil/hydraulic oil/double fat oil/silicic acid grease is better than other rubbers.
Excellent resistance to strong acid and alkali media and strong oxidants,
it can maintain a low expansion rate and shrinkage rate in strong corrosive media
such as fuming nitric acid/concentrated sulfuric acid/hydrochloric acid/hydrogen peroxide/
concentrated alkali, and can reach various limits used in the environment.
Good machining performance, electrical insulation and radiation resistance.
Good vacuum resistance and ozone resistance.
Product fetures: Surface is bright and smooth ,thickness tolerance is small .
Heat resistance, oil resistance, strong acid and alkali resistance, etc.,
can withstand the inspection of harsh environments.
Our company provides a variety of hardness fluorine rubber sheets
that can basically meet the needs of various industries.
Buyers have special technical requirements of special fluorine rubber sheets
such as insulation, cloth sandwiching, metal meshing, cloth pattern surface, etc.,
which can be customized by agreement.
Application : Mainly used in machinery, national defense industry, vacuum-resistant,
high-temperature and aging-resistant sealing materials.
The most commonly used is for punching gaskets and other seals.
Product Size :
Length:The fluorine rubber sheet is processed by calendering, which can produce the sheet of infinite length.
However, as the packaging size should be easy to pack, our conventional packaging length is 10m per roll.
Width: 1m. 1.2m. 1.5m 2m.
If you need a special width, our company can cut with fluorine rubber sheets of similar width.
Thickness: 0.5mm-10mm is the calendering method, and 11mm-20mm is the molding method.
About color: The regular colors are black, brown, white, red and can be customized
Product Specifications :
| CERTIFICATION OF ANALYSIS | |||||||||
| Name: | FKM SHEET | Size | 1.2m*3mm*10m | ||||||
| Qty: | 15pcs | Dispatch date | 2/7/2020 | ||||||
| Lot: | 9120200601730, 912020060187 | Test date: | 2/7/2020 | ||||||
| No. | Item | Test result | |||||||
| 1 | Appearance | Qualified | |||||||
| 2 | Color | Black | |||||||
| 9 | 1.2*3*10 | Thickness mm | 2.9-3.15 | ||||||
| 10 | Width mm | 1.2 | |||||||
| 11 | Length mm | 10 | |||||||
| 12 | Typical property | Gravity, g/cm3 | 1.9 | ||||||
| 13 | FKM Raw gum content ,% | 67 | |||||||
| 14 | Hardness, Shore A | 70 | |||||||
| 15 | Tensile Strength, Mpa | 9.2 | |||||||
| 16 | Elongation at break, % | 320 | |||||||
Product pictures :
