SD6536AZ petroleum product distillation apparatus (double holes) GB/T6536, ASTM D86
Purpose and scope of application
SD6536AZ petroleum product distillation apparatus (double holes) is based on the standard of the People's Republic of China GB/T6536 requirements stipulated in "the distillation of petroleum products determination method of design and manufacture, suitable for according to the standard of GB/T6536 gasoline, aviation gasoline, steam jet fuel, special boiling point solvents, naphtha, diesel oil, distillate fuel oil products and similar distillation.
Main technical parameters and technical characteristics
(1) Main technical parameters
⑴ Power supply: AC220V±10%, 50Hz.
⑵ Heating power of electric furnace: 1000W×2.
⑶ Measuring cylinder volume: 100 mL, indexing 1 mL.
The distillation flask: 125mL, in line with the requirements of GB/T6536.
⑸ thermometer: full immersion stick, scale range (-2 ~ +300) ℃ and (-2 ~ +400) ℃, 1℃.
The electric furnace plate: silicon carbide plate manufacturing, aperture is Φ 38mm, Φ 50mm.
① Temperature control range: (0 ~ 80) ℃ arbitrary setting (with refrigeration).
② Temperature control accuracy: ±0.5℃.
③ Temperature display mode: LED digital display.
(8) Compressor circulation refrigeration device
Instrument size: 760 × 520 × 500mm
Instrument weight: 36kg
| Item | GD-6536A Distillation Tester |
| Test standard | GB/T6536, ASTM D86 |
| Suitable for | gasoline, jet fuels, special boiling point solvent, naphtha, diesel oil, distillate and other petroleum products |
| Features | Can test two samples simultaneity |
| Heating power of electric furnace | 1000 W*2, heating power can be continuously adjusted |
| Volume of graduated flask | 100 ml with scale division of 1ml |
| Distillation flask | 125 ml |
| Thermometer | -2~300°C, and -2~400°C |
| Temperature controlling range | (0 ~ 80) ℃ arbitrary setting (with refrigeration). |
| Receiver compartment temperature | 1 ~ 60°C |
| Temperature controlling accuracy | ±0.5°C |
| Power supply | AC 220V±10%, 50 Hz |
| Ambient temperature: ≤+35°C | ≤+35°C |
| Relative humidity | ≤85% |
| Total power consumption | ≤2500 W |
Packing list
| S/N | Name | Quantity | Unit | Note |
| 1 | Host | 1 | set | |
| 2 | Distilled flask (125 ml) | 2 | piece | |
| 3 | Aquarium | 2 | piece | |
| 4 | Silica gel plug | 4 | piece | |
| 5 | Silicon carbide plate, aperture Φ 32mm, Φ 38mm, Φ 50mm | 2 | piece | |
| 6 | Measuring cylinder (100ml) | 2 | piece | |
| 7 | Test platform | 2 | piece | |
| 8 | power cord | 1 | piece | |
| 9 | Thermometer | 2 | piece | |
| 10 | fuse tube | 1 | piece | 10A |
| 11 | Operating instruction | 1 | copy | |
| 12 | packing list | 1 | copy | |
| 13 | Certificate of approval | 1 | copy |
Packaging & Delivery
1. Out packing: Standard export wooden case.
2. Inner packing: With careful stretch film wrap product, hard wood board+ strong bandage to fix corners.
3. Checking teams: Specialized staff to inspect and classified your goods.
4.Port Any port of China
Lead Time :
| Quantity(Sets) | 1 - 1 | 2 - 5 | 6 - 10 | >10 |
| Est. Time(days) | 6 | 20 | 30 | To be negotiated |
