Bag Type 372m2 Pulse Jet Dust Collector For Woodworking Furniture Factory
Pulse Jet Bag Type Dust Collector For Woodworking Furniture Factory
Product Description
Baghouse belongs to dry type dust collecting device to capture fine, dry, non-fibrous dust. Its filtering material is woven filtration cloth or non-woven needle felt fabric.
Pulse Jet Bag Type Dust Collector for Wood Working is a kind of improved new type high efficient pulse jet bag dust collector, which has large capacity, stable performance, easy installation, long lifetime and small maintenance workload, etc. Besides, this type dust collector has been reformed from structure and pulse valves to solve such problems as outdoor setting and low pressure of compressor air. Our power pulse bag dust collectors are self contained, weatherproof, and fully automated. if you need, we can supply and install ducting, access platforms, ventilation, instrumentation, walk-in plenums, and easy maintenance access for small or large projects.
Techinal parameters
| Model | filting area(m2) | air volume(m3/h) | filting airspeed(m/min) | working resistance(Pa) | dust removing pressure(Mpa) |
| DMC-32 | 30 | 2880-4800 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-48 | 48 | 4320-7200 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-60 | 60 | 5400-9000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-72 | 72 | 6480-10800 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-90 | 90 | 8100-13500 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-120 | 120 | 10800-18000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-150 | 150 | 13000-22500 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-180 | 180 | 16200-27000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-210 | 210 | 18900-31500 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-250 | 250 | 22500-37500 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-270 | 270 | 24300-40500 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-300 | 300 | 27000-45000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-340 | 340 | 30400-51000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-420 | 420 | 37800-63000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-500 | 500 | 45000-75000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-600 | 600 | 54000-90000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-740 | 740 | 66600-111000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-870 | 870 | 78300-130500 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-1000 | 1000 | 90000-150000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
| DMC-1100 | 1100 | 99000-165000 | 1.5-2.5 | 800-1800 | 0.4-0.6 |
