HUAWEI RRU5509t 02312GEB 700MHz 800MHz 900MHz 2x80W 2T4R For Base Station Unit
Price:
$100-$200
MOQ:
1pc
Delivery Time:
3-7 work days
Brand:
HUAWEI
Product Description
HUAWEI RRU5509t 02312GEB 700MHz 800MHz 900MHz 2x80W 2T4R For Base Station Unit
Product Description:
The HUAWEI RRU5509t 02312GEB (material code: WD5M05509TGB) is a high-performance 3-band multimode Remote Radio Unit (RRU) from Huawei's 5000 series, specifically designed for 700/800/900 MHz frequency bands with a 2T4R×3 configuration (2 transmitters and 4 receivers per band). This outdoor, weatherproof radio unit delivers 2×40W power output per band and supports 2G/3G/4G/5G multi-RAT operations, making it an ideal solution for macro site deployments requiring broad coverage and seamless network evolution. Fully compatible with Huawei's DBS3900 and DBS5900 base station systems, it offers exceptional flexibility for operators upgrading from legacy networks to 5G.
Specifications:
| Parameter | Value |
|---|---|
| Model Number | RRU5509t 02312GEB |
| Material Code | WD5M05509TGB |
| Operating Mode | 2T4R×3 |
| Frequency Range | • 700MHz: TX 758-788 MHz, RX 703-733 MHz (Band 28/n28)
|
| Power Output | 2 × 40W per band (total 240W across 3 bands) |
| Supported RATs | 2G (GSM), 3G (UMTS), 4G (LTE FDD), 5G (NR FDD), plus various multi-RAT combinations (GU, GL, UL, GUL, LM, LN, etc.) |
| Power Supply | -48VDC (operating range: -40V to -57V DC) |
| Transmission Interface | 9.8Gbps optical fiber (CPRI interface) |
| Form Factor | Outdoor, weatherproof design with natural heat dissipation (fanless) |
| Compatibility | Huawei DBS3900/DBS5900 base station systems |
| Weight | Approximately 22kg |
| Operating Temperature | -33°C to +55°C |
| Certifications | CE, FCC, RoHS compliant |
| Instant Bandwidth (IBW) | 700MHz: 30MHz, 800MHz: 30MHz, 900MHz: 35MHz |
Product Details:
If you are interested, please let us know the specific model. We will provide the best service and the best price!
