HUAWEI RRU3268 02311KVB 2600MHz 2x80W 2T4R For Base Station Unit
Price:
$100-$200
MOQ:
1pc
Delivery Time:
3-7 work days
Brand:
HUAWEI
Product Description
HUAWEI RRU3268 02311KVB 2600MHz 2x80W 2T4R For Base Station Unit
Product Description:
The HUAWEI RRU3268 02311KVB (material code: WD5MLRUH870) is a versatile 3-band multimode Remote Radio Unit (RRU) from Huawei's 3000 series, specifically designed for 700MHz (Band 28), 800MHz (Band 20), and 2600MHz (Band 7) frequency bands with a 2T2R×3 configuration (2 transmitters and 2 receivers per band). This outdoor, weatherproof radio unit delivers 2×40W power output per band and supports LTE FDD, NB-IoT, and LM (Low-Mobility) operations, making it an ideal solution for macro site deployments requiring broad coverage, multi-service support, and seamless network evolution. Fully compatible with Huawei's DBS3900 and DBS5900 base station systems, it offers exceptional flexibility for operators seeking to optimize spectrum utilization across multiple frequency layers.
Specifications:
| Parameter | Value |
|---|---|
| Model Number | RRU3268 02311KVB |
| Material Code | WD5MLRUH870 |
| Operating Mode | 2T2R×3 |
| Frequency Range | • 700MHz: TX 758-788 MHz, RX 703-733 MHz (Band 28)
|
| Power Output | 2 × 40W per band |
| Supported RATs | LTE FDD, NB-IoT, LM (Low-Mobility) |
| Power Supply | -48VDC (operating range: -36V to -57V DC) |
| Transmission Interface | 1.25/2.5/4.9Gbps optical fiber (CPRI interface), supports star, chain, or ring topology |
| Form Factor | Outdoor, weatherproof design with natural heat dissipation |
| Compatibility | Huawei DBS3900/DBS5900 base station systems |
| Weight | Approximately 14kg |
| Operating Temperature | -33°C to +55°C |
| Certifications | CE, FCC, RoHS compliant |
| Instant Bandwidth (IBW) | 700MHz: 30MHz, 800MHz: 20MHz, 2600MHz: 70MHz |
| Cascading Capability | Supports up to 4-level cascading for flexible site design |
| CPRI Ports | 2 ports for enhanced connectivity options |
Product Details:
If you are interested, please let us know the specific model. We will provide the best service and the best price!
