Single / Double Wall Corrugated Pipe Production Extrusion Line PLC Control
Single / Double Wall Corrugated Pipe Production Extrusion Line PLC Control
1. Normal speed
| Model | Pipe diameter(mm) | Extruder model | Output(kg/h) | Total power(kw) | Module No.(pairs) | Production line speed(m/min) |
| SD-12 | Φ6-12 | SJ-45 | 40-60 | 16 | 42 | 6-12 |
| SD-32 | Φ16-32 | SJ-50 | 50-70 | 23 | 48 | 6-12 |
| SD-63 | Φ20-63 | SJ-65 | 60-100 | 38 | 56 | 4-8 |
| SD-80 | Φ50-80 | SJ-75 | 70-130 | 64 | 72 | 3-8 |
2. High speed
| Model | Pipe diameter(mm) | Extruder model | Output(kg/h) | Total power(kw) | Module No.(pairs) | Production line speed(m/min) |
| SD-14 | Φ7-14 | SJ45/SJ50 | 40-80 | 25 | 70 | 10-30 |
| SD-58 | Φ16-50 | SJ65/SJ75 | 60-120 | 46 | 74 | 10-30 |
Description of Single / Double Wall Corrugated Pipe Production Extrusion Line PLC Control:
This corrugated production line can be used to produce single-wall or double wall corrugated pipes of PE, PP, PVC, EVA continuously, as well as PA corrugated pipes.
It calso called pvc corrugated pipe extruder/pvc corrugated pipe machine/pvc corrugated pipe production line/pe corrugated pipe extruder/pe corrugated pipe machine/pe corrugated pipe extrusion line/pe corrugated pipe production line.
Characteristics and Application of Pipe:
Plastic single-wall corrugated pipes have features of high temperature resistance, resistant to corrosion and abrasion, high intensity, good flexibility, etc.
They are widely used in fields of auto wire, electric thread-passing pipes, circuit of machine tool, protective pipes of lamps and lanterns wire, tubes of air conditioner and washing machine,These corrugated pipes are especially used as wires of the up-market cars, electric conduit pipe passing, washing machine, air conditioner pipe, lamp pipes, etc.
Our Advantages
- Always upgrade new technology
- We consider different buyers' different request, try our best to meet your satisfy!
Multi-functions
- Strong machine using long life
We Win Win Machinery can supply major machines as below 10items:
1,Mixing unit (Vertical , or Horizontal),high speed mixer~~~for PVC powder;
2,Single screw extruder;
3,Conical twin screw extruder;
4, 2layer; 3 layer;4 layer PPR pipe co-extrusion line; PPR, PE, HDPE, PE-RT pipe production line;
5, Corrugated pipe extrusion line (Single wall corrugated; Double wall corrugated);
6, 3 layer PVC pipe co-extrusion line; PVC pipe production line;
7, PVC 2 cavity pipe production line;
8, PVC 4 cavity pipe production line;
9,Pipe belling machine;
10, Granulating line (PE, PP, PVC)
Qingdao Win Win Machinery Co., Ltd. is a new type of high-tech enterprise specializing in R & D and production of extrusion machine. The company's main products -- plastic pipe extrusion complete production line.
Our production technology of single / double wall corrugated pipe machine, carbon spiral pipe machine and solid wall pipe machine has always been in the leading position in the industry.
If you need plastic extrusion equipment, please feel free to contact me!
Packaging & Shipping
Tel:86-158 4530 5907 (Wechat/skype/whatsapp)
E-mail: libing@qdwinwin.cn
Web1: www.qdwinwin.cn
Web2: www.corrugatedpipeextrusionline.com
Address: Jiaoxi Industrial Park, Jiaozhou, Qingdao, Shandong, China
