HDPE Double Wall Sewage Pipe Extruder Machine For Plumbing
Plumbing System Large Diameter HDPE Double Wall Corrugated Plastic Sewage Pipe Extruder Machine
Plumbing System Large Diameter HDPE Double Wall Corrugated Plastic Sewage Pipe Extruder Machine features
1. Light weight, high ring stiffness.
2. Easy to construct, short project period, low comprehensive cost.
3. Smooth inwall, large quantity of flow.
4. Corrosion resistance, no scaling, no need to dredge.
5. Soft joint, high ability of nonuniform sedimentation resistance, no leakage.
| Diameter DN/ID (mm) |
Minimum mean internal meridian Dim MIn(mm) |
Suggestion connection length(mm) | Minimum laminated wall thickness(mm) | Minimum inner wall thickness (mm) |
| 200 | 198 | 54 | 1.5 | 1.1 |
| 300 | 296 | 65 | 2.0 | 1.7 |
| 400 | 394 | 74 | 2.5 | 2.3 |
| 500 | 492 | 85 | 3.0 | 3.0 |
| 600 | 588 | 96 | 3.5 | 3.5 |
| 800 | 785 | 118 | 4.5 | 4.5 |
| 1000 | 985 | 140 | 5.0 | 5.0 |
| 1200 | 1185 | 162 | 5.0 | 5.0 |
Strong resistance to external pressure of Plumbing System Large Diameter HDPE Double Wall Corrugated Plastic Sewage Pipe Extruder Machine
The outer wall of Plumbing System Large Diameter HDPE Double Wall Corrugated Plastic Sewage Pipe Extruder Machine has a ring-shaped corrugated structure, which greatly enhances the ring stiffness of the pipe, thereby enhancing the resistance of the pipe to soil loads. In this performance, HDPE double-arm corrugated pipe has obvious advantages compared with other pipes.
Low temperature and impact resistance
The embrittlement temperature of Plumbing System Large Diameter HDPE Double Wall Corrugated Plastic Sewage Pipe Extruder Machine is -70ºC. Under normal low temperature conditions (above -30ºC), special protective measures are not necessary for construction. The HDPE double-wall pipe makes it convenient in winter.
