42crmo Steel Pinion Gear Cast And Forged Ball Mill Spare Parts
42CrMo Steel Cast And Forged Pinion Gear For Ball Mill Spare Parts
1. Pinion design
Bored solid on shaft / integral self aligned spur, helical or double helical
Materialization forged alloyed steel through hardened, case hardened or quenched and tempered
Spur, helical or double helical carburized induction nitrided
2. Characteristics
• Gear cutting with hobs
• The gear quality is checked by profile tester
• Tooth flank modification
• Profile correction
• Lead correction (straight/barrel)
• Designs /ratios according to ISO-DIN-A.G.M.A.
• FEM/FEA simulation software
Customized Carbon Steel Cement Ball Mill Spare Parts Mill Pinion Gear Spur Gear
3. Pinion gear material
42CRMO STEEL DATA
| C : 0.38-0.45% |
| Si: 0.17-0.37% |
| Mn: 0.50-0.80% |
| S : Allow residual content <0.035% |
| P : Allow residual content <0.035% |
| Cr: 0.90-1.20% |
| Ni: Allow residual content <0.030% |
| Cu: Allow residual content <0.030% |
| Mo: 0.15-0.25% |
MECHANICAL DATA
| Tensile Strength σb (MPa): >1080(110) |
| Yield point σs (MPa): >930(95) |
| Reduction of area ψ (%): >45 Akv (J) |
| Impact absorbing energy Akv(J): >63 |
| Impact toughness value αkv (J/cm2): >78(8) |
| Elongation σ5 (%): >12 |
| Hardness: <217HB |
42CrMo Steel Cast And Forged Pinion Gear For Ball Mill Spare Parts
4. Applications
Our pinions are applied in the cement and minerals industries:
Ball - mills
ROD - mills
Semi Autogeneous Grind (SAG)
Rotary kilns/coolers/dryers
42CrMo Steel Cast And Forged Pinion Gear For Ball Mill Spare Parts
42CrMo Steel Cast And Forged Pinion Gear For Ball Mill Spare Parts
FQA
Q: Why we believe in luoyang zhongtai industries co., ltd:
A: 1. More than 30 years experience.
2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts.
3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates.
Q:Delivery time :
A: Parts lead time 1-2months, machines 2-3months.
Q:Payment terms :
A: Accept payment type: T/T, L/C, Western union,Cash. 30% deposit when signed contract. Full payment paid before shipping.
Q: Quality warranty?
A: Guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply.
Q: After sales service?
A: We can supply technical guide for machines running test and parts maintenance if end user needs.
After-sales service
LUOYANG ZHONGTAI INDUSTRIES able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS
