GB/T9444-88 Cast Iron HB 250 Mill Girth Gear And Rotary Kiln Girth Gear Factory Price
Price:
negotiable / Ton
MOQ:
1 Ton/Tons
Delivery Time:
Negotiable
Brand:
ZTIC
Product Description
Products Description
Girth Gears: Rotary kiln Girth Gear,ball mill Girth Gear
|
Product Name |
Steel girth spur gear |
|
Weight |
Max 120 MT single piece |
|
Applications |
industries |
|
Module Range |
10 Module to 70 Module. |
|
Diameter |
Min 100 mm to16000 mm. |
|
Weight |
Max 120 MT single piece. |
|
Gear Cutting Capacity |
100mm diameter to 16000mm diameter,10Module to 70Module |
| External teeth | |
| Maximum diameter | 16000 mm |
| Toothed face width | 1700 mm |
| Maximum module | 45 by hob |
| Maximum module | 65 gear finishing cutter |
| Internal teeth | |
| Maximum Diameter | 6500 mm |
| Maximum module | 25.4 |
| Toothed face width | 400 mm |
Girth Gears offered find extensive application in different industry sectors including in sponge iron plants, steel & cement
industry, mining industry, wind mills as well as in other industry sectors. These are made available in module range of 10 Module
to 70 Module and in minimum diameters of 100 mm to 15000 mm. Further, these comprise maximum weight of 70 MT single pieces. Here
the range of hardened & ground gear boxes/gears comprise Worm gear boxes, Helical / Double helical gears/gearboxes, Helical-Bevel
gearboxes, Planetary Gearboxes and others.
industry, mining industry, wind mills as well as in other industry sectors. These are made available in module range of 10 Module
to 70 Module and in minimum diameters of 100 mm to 15000 mm. Further, these comprise maximum weight of 70 MT single pieces. Here
the range of hardened & ground gear boxes/gears comprise Worm gear boxes, Helical / Double helical gears/gearboxes, Helical-Bevel
gearboxes, Planetary Gearboxes and others.
|
Item
|
Structural features
|
Processing measure
|
Test content
|
|
Girth Gear
|
(1)GS42CrMo4Alloy Steel (corporate proprietary standards)
HB 220~240 (2)semi-structured, Y-Spoke (3)Helical (4) reasonable sealing and alignment structure of alloy steel (corporate proprietary standards) |
(1) outer steel refining (R-H argon and vacuum treatment)
(2) proprietary cold mold hanging sand technology to ensure the casting, the teeth dense (3) normalizing (proprietary technology) to ensure that the tooth surface hardness After (4)rough hobbing, release time, repair the joint surface, then fine roll (5) proprietary homemade hob fine hobbing |
(1)castings mechanical properties and chemical composition (internal standard)
(2) roughing after sonic testing (3)semi-finishing, finishing after ultrasonic testing and magnetic particle inspection (4) tooth surface magnetic particle inspection, hardness test (5)tooth tolerance check (6) the factory assembly load test to check the accuracy of the size of gear |
FAQ
Q: Why we believe in luoyang zhongtai industries co., ltd: A: 1. More than 30 years experience. 2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts. 3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates. Q:Delivery time A: parts lead time 1-2months, machines 2-3months. Q:Payment terms A: Accept payment type: T/T, L/C, Western union,Cash. 30% deposit when signed contract. Full payment paid before shipping Q: Quality warranty? A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply. Q: After sales service? A: we can supply technical guide for machines running test and parts maintenance if end user needs.
Mill Girth Gear
