30t/H Cement 5000kw Vertical Grinding Mill and slag vertical mill for steel plant
Product Description
CITICIC holds the leading position among all building materials equipment suppliers in China, and is the national export base for complete equipment supply.
|
Model
|
Grinding diameter
d(mm) |
Roll diameter
d(mm) |
Roller number
(n) |
Standard power
P(kw) |
capacity
Q(t/h) |
|
LKCM30.31
|
3,000
|
1,600
|
3
|
1250
|
55~60
|
|
LKCM32.31
|
3,200
|
1,700
|
3
|
1600
|
65~80
|
|
LKCM35.41
|
3,500
|
1,800
|
4
|
1800
|
85~100
|
|
LKCM40.41
|
4,000
|
1,900
|
4
|
2500
|
115~125
|
|
LKCM43.41
|
4,300
|
2,120
|
4
|
3000
|
135~145
|
|
LKCM46.41
|
4,600
|
2,240
|
4
|
3350
|
150~160
|
|
LKCM48.41
|
4,800
|
2,240
|
4
|
3550
|
170~180
|
|
LKCM50.41
|
5,000
|
2,360
|
4
|
3900
|
190~200
|
|
LKCM53.41
|
5,300
|
2,500
|
4
|
4600
|
210~230
|
|
LKCM56.61
|
5,600
|
2,500
|
Our vertical raw mill has various advantages when compared with other similar machines. Detailed information will be given in the following.
1. High grinding efficiency: advanced grinding principles makes it possible to save as much as 20~30% power consumption when compared with the ball mill. With the increasing of moisture content, it can save more and more electricity.
2. Strong drying capacity: it can make use of the hot waste gases from the kiln to do drying, and it is capable of drying and grinding raw materials with moisture content as much as 15%.
3. Small in size, and simple process flow: it has integrated crushing, drying, grinding, separating and conveying into one body.
4. Low noises and little dust: there is no direct contact between the grinding rollers and grinding disc. So metallic impact is avoided and its noises is 20~25 decibels lower when compared with ball mill. Totally closed negative pressure operation has employed by this vertical raw mill, so there is no dust during the operation, which can help to keep the production environment clean.
5. Low wear rate and little metallic pollution: its metal wear is only 5~10g/t.
6. With stable chemical composition and even particle size, its products are quite easy to calcine.
| Model | Grinding diameter D |
Roll diameter D |
Roller number | Standard power P |
capacity Q |
| (mm) | (mm) | (n) | (kW) | (t/h) | |
| LKMR22.30 | 2200 | 1400 | 3 | 550 | 70 |
| LKMR26.30 | 2600 | 1600 | 3 | 790 | 100 |
| LKMR28.30 | 2800 | 1750 | 3 | 900 | 115 |
| LKMR30.30 | 3000 | 1700 | 3 | 1000 | 120 |
| LKMR32.30 | 3200 | 1500 | 3 | 1400 | 160 |
| LKMR34.30 | 3400 | 1500 | 3 | 1600 | 180 |
| LKMR36.41 | 3600 | 1600 | 4 | 1800 | 200 |
| LKMR38.41 | 3800 | 1700 | 4 | 1900 | 230 |
| LKMR40.41 | 4000 | 1800 | 4 | 2240 | 260 |
| LKMR43.41 | 4300 | 1900 | 4 | 2500 | 310 |
| LKMR46.41 | 4600 | 2060 | 4 | 3150 | 350 |
| LKMR48.41 | 4800 | 2240 | 4 | 3350 | 390 |
| LKMR50.41 | 5000 | 2360 | 4 | 3500 | 420 |
| LKMR53.41 | 5300 | 2500 | 4 | 3800 | 470 |
| LKMR56.41 | 5600 | 2600 | 4 | 4500 | 540 |
| LKMR59.61 | 5900 | 2600 | 6 | 5000 | 610 |
| LKMR63.61 | 6300 | 2700 | 6 | 6000 | 720 |
CITICIC began in 1956-The largest mining equipment and cement equipment manufacturers in China.CITICIC is a global supplier of technology and services to customers in the process industries,including
Mining,Construction,Metallurgical,Environmental,Power,Chemical,Marine,Casting&Forgings.
CITIC IC produces over 200,000 tons of quality equipment annually. Our products include grinding mills, scrubbers,crushers, kilns, coolers, hoists, reducers, steam turbines and compressors. CITIC IC also manufactures heavy castings and forgings, as well as electric/hydraulic control and lubrication systems.
Our factory in Luoyang covers more than 3 million square meters, of which 2 million square meters is under cover. It has a total workforce of approximately 10,000 employees of which more than 1,200 are engineers.
CITIC IC produces over 200,000 tons of quality equipment annually. Our products include grinding mills, scrubbers,crushers, kilns, coolers, hoists, reducers, steam turbines and compressors. CITIC IC also manufactures heavy castings and forgings, as well as electric/hydraulic control and lubrication systems Etc.
CITICIC able to provide:
1. ENGINEERED SPARES - DESIGN AND MANUFACTURING
2. LARGE VOLUME STEEL AND IRON CASTING FOUNDARIES
3. HUGE MACHINE SHOP CAPABILITIES
4. TRAINING PROGRAMMES
5. PREVENTATIVE MAINTENANCE PROGRAMS
6. PREVETATIVE MAINTENANCE SERVICES
7. COMPREHENSIVE MAINTENANCE PROGRAMS
CITIC’s Field Service Engineers are trained specifically in the CITIC brand group products but are capable of undertaking the servicing of other OEM brands.
Our technicians are equipped with the most advanced technological diagnostic equipment available to trouble shoot your equipment to optimise performance and minimise down time.
CITICIC also has an extensive capability in supplying all you consumable and electrical/ mechanical spare part needs.
Quality Control
Physical & Chemical Identification Center
ZTIC owns a professional testing and metrology institute which provides advanced testing methods such as nondestructive testing, industrial chemical analysis, metallographic testing and analysis, mechanical testing, sample preparation, meter/length measurement, weighing apparatus verification, and weighman inspection. Our metrology institute has taken a leading role in China.
ZTIC owns nearly two hundred types of advanced testing equipment, nine different measurement standards and nearly twenty types of world-class testing equipment which have been imported from international locations such as Germany, Japan, USA, UK and Belgium.
