8-55 Tph Industrial Screw Conveyor Continuous Screw Conveyor System
Price:
negotiable
MOQ:
1 set
Delivery Time:
30 days
Brand:
ZTIC
Product Description
8-55 tph Screw conveyor continuous and highly efficient operation
Application:
The screw conveyor is widely used for conveying powder, granule or small block materials, usually it could be used with the suit sieving machine.
Features:
1.The motor reducer could be installed on the top or the bottom.
2.Conveyor has big transport capacity, long distance available.
3.Stable and controllable start, continuous and highly efficient operation.
4.The conveying could be the level or the inclined.
5.The blade could be entity spiral or belt spiral.
Technical parameters :
| Diameter(mm) | conveying angle | Power(kw) | Capacity(t/h) | |
| 108 | 0-60 | 1.5-2.2 | 8 | |
| 159 | 0-60 | 2.2-3 | 16 | |
| 219 | 0-45 | 3-4 | 30 | |
| 273 | 0-45 | 4-5.5 | 40 | |
| 300 | 0-30 | 5.5-7.5 | 45 | |
| 400 | 0-30 | 7.5-11 | 50 | |
| 500 | 0-30 | 7.5-11 | 55 | |
