85% Output High Efficiency Fine Crusher Below 5mm Lower Motor Power
High Efficiency Fine Crusher 85% output below 5mm lower motor power
Iron Ore Mining Machine And Mining Equipment Fine Crusher
High efficiency fine crusher is the most effective and reliable gravel machine. Our fine crusher suitable for crushing granite, basalt, limestone, river gravel, cement clinker, quartz, iron ore, bauxite and other minerals. Also the fine crusher could apply to artificial Sand, highway, railway, water conservancy, airport, construction, cement, refractory, metallurgical and other industries for the production of superior quality stone.
Working principle
When the Fine Crusher is working, materials are crushed primarily in the first crushing chamber by the high speed moving rotor against the hammer, and then enter the secondary chamber for fine crushing, at last, the final materials are discharged.
Features
1. Feeding size: 120mm-200mm
2. More than 85% of output below 5mm
Even particle size small, higher output, more durable plate hammer
4. lower motor power, don’t need thirdly crushing
5. Simple structure, easy maintenance and stable running
| Model | Feed Size | Output Size | Capacity | Motor Power | Rotor speed | Dimension |
| (mm) | (mm) | (t/h) | (kw) | (r/min) | (m) | |
| 800*400 | ≤120 | ≤10 | 30-40 | 37-45 | 860 | 2.1*1.4*1.7 |
| 800*600 | ≤180 | ≤10 | 40-50 | 45-55 | 860 | 2.1*1.62*1.7 |
| 800*800 | ≤180 | ≤10 | 50-70 | 45-55 | 860 | 2.1*1.84*1.96 |
| 1010*1010 | ≤180 | ≤10 | 60-75 | 55-75 | 720 | 2.1*1.84*1.96 |
| 1200*1000 | ≤180 | ≤10 | 100-110 | 90-110 | 590 | 2.45*1.6*1.96 |
| 1200*1200 | ≤180 | ≤10 | 120-150 | 110-132 | 590 | 3*2.16*2.5 |
