30-800 Tph Stone Crusher Machine Impact Crusher High Efficiency
Price:
negotiable
MOQ:
1 set
Delivery Time:
1-2 months
Brand:
ZTIC
Product Description
30-800 tph high-efficiency low cost crushing machine Impact crusher
Impact crusher is a new type of high-efficiency crushing machine with the features of small size, simple structure, large crushing ratio.
Features
Seamless link, easy repair, low cost, reliable operation.
High impact resistance, wear resistance, big impact force.
Low wear rate, high comprehensive benefits.
Technical Parameters
| Model | Specifications (mm) |
Feed opening (mm) |
Max.feeding side length (mm) |
Capacity (t/h) |
Power (kw) |
Total weight (t) |
Dimensions (L×W×H) (mm) |
| PF-1007 | Φ1000×700 | 400×730 | 300 | 30-70 | 37-45 | 12 | 2330×1660×2300 |
| PF-1010 | Φ1000×1050 | 400×1080 | 350 | 50-90 | 45-55 | 15 | 2370×1700×2390 |
| PF-1210 | Φ1250×1050 | 400×1080 | 350 | 70-130 | 110 | 17.7 | 2680×2160×2800 |
| PF-1214 | Φ1250×1400 | 400×1430 | 350 | 100-180 | 132 | 22.4 | 2650×2460×2800 |
| PF-1315 | Φ1320×1500 | 860×1520 | 500 | 130-250 | 220 | 27 | 3180×2720×2620 |
| PF-1520 | Φ1500×2000 | 830×2040 | 700 | 300-550 | 315-400 | 50.6 | 3959×3564×3330 |
| PF-1820 | Φ1800×2000 | 1260×2040 | 700 | 600-800 | 630-710 | 83.21 | 4400×3866×4009 |
