Wireline Torsion Tester Wireline Pressure Control Equipment

I. Overview:
The wire quality tester (Type I) is also known as the wire torsion tester. It is an instrument used for wire torsion experiments. Through the torsion test, the number of turns when the wire is broken is counted and compared with the standard number of broken turns of the wire to determine the qualitative test. Whether the well wire can continue to be used.
II. Main technical performance:
Applicable steel wire diameter: 0.092", 0.108", 0.125"
Total weight: 4.6Kg
Length × width × height (mm): 452.5 × 112 × 76.5
III. Structural features:
The steel wire quality inspector (type I) is mainly composed of a shell, an upper cover, an adjusting plate, a spring, a bearing seat, a connecting rod, and a handle. The specific structure is shown in the attached drawings.
According to API9A standard, the minimum number of twisted and broken turns of 0.092" steel wire is about 23 turns, and the minimum number of twisted and broken turns of 0.108" steel wire is about 20 turns.
IV. Maintenance:
Grease the bearings regularly.
