High Polymer 200mm Conveyor Head Roller For Building Materials
High Polymer 200mm Conveyor Head Roller For Building Materials
High Polymer Conveyor Belt Roller Industrial Heated Rollers Conveyor Steel Roller
Conveyor Roller
The Conveyor Belt roller retains all the excellent properties of ultra-high molecular weight polyethylene. The wear resistance is 7 times that of steel and 3 times that of nylon. At the same time, it also has the characteristics of anti-friction, self-lubricating, anti-impact, noise cancellation and anti-vibration, anti-adhesion, anti-corrosion, anti-aging and so on. After being put on the market, UHMWPE rollers have been proved to withstand long-term use and receive good comments from customers. Currently UHMWPE rollers are widely used in metallurgical mines, coal mines, chemical industry, grain storage, building materials, ports, salt fields, electricity and other industries, which is the best alternate to metal rollers. Compared with traditional metal conveyor rollers, UHMWPE rollers have significant economic benefits in terms of improving transportation capacity, protecting belt, reducing maintenance, energy saving and consumption reduction.
Specification
| Roller Dimension | Roller Shell Thickness | Bearing Model No. | Roller Dimension | Roller Shell Thickness | Bearing Model No. |
| 89*190 | 13 | 6204 | 108*315 | 14 | 6205 |
| 89*200 | 13 | 6204 | 108*375 | 14 | 6205 |
| 89*240 | 13 | 6204 | 108*380 | 14 | 6205 |
| 89*250 | 13 | 6204 | 108*455 | 14 | 6205 |
| 89*305 | 13 | 6204 | 108*465 | 14 | 6205 |
| 89*315 | 13 | 6204 | 108*525 | 14 | 6205 |
| 89*600 | 13 | 6204 | 108*530 | 14 | 6205 |
| 89*750 | 13 | 6204 | 108*950 | 14 | 6205 |
| 89*750 | 13 | 6204 | 108*1150 | 14 | 6205 |
| 89*950 | 13 | 6204 | 108*1400 | 14 | 6205 |
| 108*1600 | 14 | 6205 | |||
| Roller Dimension | Roller Shell Thickness | Bearing Model No. | Roller Dimension | Roller Shell Thickness | Bearing Model No. |
| 133*380 | 15 | 6305 | 159*465 | 15 | 6305 |
| 133*465 | 15 | 6305 | 159*530 | 15 | 6305 |
| 133*530 | 15 | 6305 | 159*1400 | 15 | 6305 |
| 133*1150 | 15 | 6305 | 159*1600 | 15 | 6305 |
| 133* 1400 | 15 | 6305 | |||
| 133*1600 | 15 | 6305 |
Performance of products:
1. Good performance of self-lubrication, wear resistance and no caking. The surface of roller is not easy to scale.
2. Low friction coefficient and it is good for belt.
3. Flexible and smooth movement, and low driving power consumption.
4. Light weight, easy installation and replacement. Reduce the labor intensity and maintenance.
5. The labyrinth seals makes waterproof and dustproof effect more significant.
