Heavy Duty Anticorrosion Conveyor Steel Roller High Precision For Conveyor Systems
Heavy Duty High Precision Conveyor Steel Roller For Conveyor Systems
1. Conveyor Steel RollerApplication:
The idlers are playing a important part in the belt conveyor system.
They consist in the entire transport process to support the belt and move the materials loaded on the belt.
2. Conveyor Steel RollerFeatures:
Fine welding tube ensure the rollers with low vibration and noise;
Special design and particular labyrinthine seal style prevent the corrosion by impurity, water and air etc.;
3. Working life: 30,000 - 50,000 hours.
4. Conveyor idler material ranges:
Steel idler Nylon idler Ceramic idler Plastic idler HDPE idler
5. Conveyor idler type ranges:
Troughing idler Parallel idler Transition idler Cushion idler
Conveyor roller parameters
| Material of tube | Tube diameter&Thickness | WT | D1 | D2 |
| Galvanized steel tube + plastic tapper cover | Φ 50*1.5 | 250 | Φ 52.9 | Φ 68.9 |
| 300 | Φ 56 | Φ 74.9 | ||
| 350 | Φ 52.9 | Φ 74.9 | ||
| 400 | Φ 56 | Φ 81.1 | ||
| 450 | Φ 52.9 | Φ 81.1 | ||
| 500 | Φ 56 | Φ 87.4 | ||
| 550 | Φ 52.9 | Φ 87.4 | ||
| 600 | Φ 56 | Φ 93.7 | ||
| 650 | Φ 52.9 | Φ 93.7 | ||
| 700 | Φ 56 | Φ 100 | ||
| 750 | Φ 52.9 | Φ 100 | ||
| 800 | Φ 56 | Φ 106.3 | ||
| 850 | Φ 52.9 | Φ 106.3 |
Carrying Idler
Carrying idler has corrosion resistance, strong wear resistance, good sealing performance, long service life, and can reduce the comprehensive cost of the belt conveyor and the maintenance time.
