Faw Engine Diesel Generator Soundproof 45kva 36kw
Price:
Negotiable
MOQ:
1SET
Delivery Time:
30 days
Brand:
Hosem Power
Product Description
China Brand FAW Engine 45kVA 36kW Diesel Generator Soundproof with Good Price
Product Description
| Model | A-XC50HS | |
| Standby Power | kVA | 50 |
| kW | 40 | |
| Prime Power | kVA | 45 |
| kW | 36 | |
| Frequency | Hz | 60 |
| Output Voltage | V | 240 |
| Oil Consumption | L/H | 0.03 |
| Dimension For Open-type | mm | 1750 X 800 X 1150 |
| Weight For Open-type | kg | 780 |
| Dimension For Soundproof | mm | 2100 X 900 X 1250 |
| Weight For Soundproof | kg | 1100 |
| Engine Model | 4DX21-61D | |
| No.of Cylinder | 4 Cylinder in line | |
| Bore | mm | 102 |
| Stroke | mm | 118 |
| Displacement | L | 3.86 |
| Cooling Fan Air Flow | m3/min | Turbocharged |
| Compress Air Flow | m3/min | 1800 |
| Exhaust Gas Flow | m3/min | N.A. |
| Exhaust Gas Temperature | ℃ | 500 |
| Lubrication Oil Capacity | L | 13 |
| Cooling Water Capacity | L | N.A. |
| Starting Voltage | V | 24 |
| Engine Max.Output Power | kW | 50 |
| Alternator Model | ASF184H | |
| Alternator Brand | Hosem | |
| Rate Output | kVA | 45 |
| Frequency | Hz | 60 |
| Altitude | M | ≤1000 |
| Insulation | Class H | |
| Protection Grade | IP23 | |
| Alternator for choice | We also have Leroy Somer, Marathon, Mecc Alte and Chinese brand Brushless alternator for your choice. | |
| Control Panel Model | AF500 | |
| Controller | Deepsea Brand Model DSE7320 | |
| Function of control panel | Automatic genset start/stop | |
| Automatic battery charger | ||
| Emergency stop | ||
| AMF (Automatic Mains Fault) | ||
| Remote control | ||
| Microprocessor-based design | ||
| LED alarm indication and Sound alarm | ||
| Display of the controller | Generator voltage: Uab, Ubc, Uca | |
| Generator current: Ua, Ub, Uc | ||
| Generator temp.: ℃/℉ both display | ||
| Generator frequency: Hz | ||
| Generator power: kW, kVA, kWh, kVAr, kVArh, kVAh | ||
| Generator starts count: 999999 times (Max) | ||
| Generator pressure: kPa/Psi/Bar both display | ||
| Charging Voltage: V | ||
| Battery Voltage: V DC | ||
| Protection of Diesel Generator | Over / Under Speed Alarm and Shutdown | |
| Start / Stop Failure Alarm | ||
| Over Current Alarm and Shutdown | ||
| Under / Over Generator Voltage Alarm and Shutdown | ||
| Low Oil Pressure Alarm and Shutdown | ||
| High Engine Temperature Alarm and Shutdown | ||
| Over Load Alarm and Shutdown | ||
| Low and High Battery Voltage Alarm | ||
| Lose of Speed Signal Alarm and Shutdown | ||
| Charge Fail Alarm | ||
Product Features
1. Hosem Power offers expert solutions for the design, application, and after-sales support of generators, ensuring you have the right product for your needs.
2. Hosem Power focuses on Innovative and Flexible diesel generator set Design, allowing them to operate autonomously or independently as per your requirements.
3. The China Brand FAW Engine genset is equipped with stronger heavy-duty rubber anti-vibration mountings, ensuring stability during operation and reducing vibration-related wear and tear.
4. 45kVA 36kW Diesel Generator with the base fuel tank features baking paint, enhancing its durability and resistance to corrosion, ensuring a longer lifespan for the genset.
5. The canopy is powder coated with a durable powder type, offering a longer service life. This coating provides protection against wear and fading, maintaining the aesthetic appeal of the genset.
6. The genset incorporates a maintenance-free battery and a high-quality battery charger, ensuring hassle-free operation and reducing the need for frequent maintenance.
7. Hosem Power uses high-standard wiring and renowned brands (such as Chint/Delixi) for relays, indicators, fuse breakers, meters, and other components, ensuring the reliability and longevity of the genset.
8. The genset is equipped with a non-return valve, preventing the backflow of fluids and ensuring the efficient and safe operation of the system.
Hosem Power's 45kVA FAW diesel genset combines innovation, quality, and reliability to provide a robust power solution for your diverse needs.
