180kW 225kVA Water Cooling Diesel Power SDEC Generator Electric Generators
Price:
Negotiable
MOQ:
1SET
Delivery Time:
30 days
Brand:
Hosem Power
Product Description
180kW 225kVA Water Cooling Diesel Power SDEC Generator Electric Generators
Product Features:
- 1. Equipped with an SDEC engine, its efficient fuel consumption of 50.6 liters per hour at 100% load, ensures cost-effective operation.
- 2. The controller offers full protection with alarms and shutdowns for various faults, including high coolant temperature, low oil pressure, and overload, enhancing operational safety.
- 3. The soundproof version of the genset has a noise level of just 72 dBA at 7 meters, making it suitable for use in noise-sensitive environments.
- 4. The genset features a robust design with a copper radiator for double-deck cooling, capable of handling ambient temperatures up to 50ºC, ensuring reliable performance in harsh conditions.
- 5. Available in both open-type and soundproof versions, this genset can be customized to meet specific needs, including dimensions and weight variations to suit different installation requirements.
- 6. The diesel genset offers a rated output of 225kVA and includes options for renowned brands of alternators like Leroy Somer, Marathon, and Mecc Alte, ensuring high reliability and performance.
- 7. Designed as an emergency standby power source, the genset includes a smart battery charger (Smartgen Model BAC06A) and an emergency stop button, ensuring quick and reliable start-up when needed.
Technical Parameters:
| Generator Set Specification | ||
| Model | A-SH250S | |
| Max. Power | kVA | 250.0 |
| kW | 200.0 | |
| Rate Power | kVA | 225.0 |
| kW | 180.0 | |
| Frequency | Hz | 50 |
| Rate Voltage | V | 400/230 |
| Rate Current | A | 324.8 |
| Dimension For Open-type Genset | mm | 2550 X 990 X 1650 |
| Weight For Open-type Genset | kg | 1870 |
| Dimension For Soundproof Genset | mm | 3500X 1200 X 1800 |
| Weight For Soundproof Generator | kg | 2500 |
| Noise Level at 7 Meters | dBA | 75 |
| Fuel Tank Capacity | Liters | 280 |
| Battery | Two of Free Maintenance Battery | |
| Engine Specification | ||
| Engine Manufacturer | Shanghai Diesel Engine Co., Ltd. | |
| Engine Brand | SDEC | |
| Engine Model | SC9D310D2 | |
| No. of Cylinder | 6 Cylinder in line | |
| Aspiration | Turbocharged and Air to Air Aftercooled | |
| Governor | Electric | |
| Engine Max. Output Power | kW | 228 |
| Displacement | L | 8.280 |
| Starting Voltage | V | 24 |
| Bore | mm | 114 |
| Stroke | mm | 144 |
| Lubrication Oil Capacity | L | 22 |
| Compression Ratio | 18 : 1 | |
| Intake Air Flow | M3/Min | 16.4 |
| Fuel Consumption at 100% Load | L/H | 50.6 |
| Alternator Specification | ||
| Alternator Manufacturer | Fuzhou Hosem Power Co., Ltd. | |
| Alternator Model | ASF274J | |
| Alternator Brand | Hosem | |
| Rate Output | kVA | 225 |
| Frequency | Hz | 50Hz |
| Current | A | 324.8 |
| Insulation | Class H | |
| Voltage Regulation | SX440 | |
| Protection Grade | IP23 | |
| Working Temperature without Output Decrease | ≤1000m | |
| Phase | 3 Phase | |
| Temperature Rise | 125 Degree Celsius | |
| Alternator for optional | Leroy Somer, Marathon, Mecc Alte and Hosem Brushless alternator for optional | |
| Control Panel Specification | ||
| Controller Brand | Deepsea | |
| Controller Model | DSE7320 | |
| Breaker Brand | Delixi | |
| Breaker Capacity | A | 400 |
| Battery Charger | Smartgen Model BAC06A | |
| Emergency Stop Button | Supply | |
| Automatic Mains Fail (AMF) | Supply | |
| Fuel Level | Supply | |
| Automatic Transfer Switch | ATS as optional part | |
| Mains Monitor | Supply with AMF Function | |
| The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm). | ||
| Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller. | ||
Choose Hosem Power Diesel Generator for a dependable, mobile power solution that delivers exceptional performance and ease of use. Contact us today to learn more!
