Small 10 Tons Construction Truck Trailer Hydraulic Mobile Truck Crane 80km/H
Price:
USD 20000-25000 per set
MOQ:
1 UNIT
Delivery Time:
35 work days
Brand:
GENRON
Product Description
| 10 tons Truck Crane is a kind of crane fitted on a common car chassis or special automobile chassis, its driving cab and lifting control cab is set separately. This kind of crane is featured by good maneuverability and quick swing speed. It must be outrigger supported when working, and can't load, also not suitable for work in soft or muddy ground |
Specification: 10 ton Hydraulic Mobile Mounted Truck Cranes
| Product model | GVCT-1O | Main hook winch | Oblique axis motor |
| Maximum lifting weight | 10000KG | Secondary hook winch | High and low speed winch |
| Max. Lifting Height | 34m | Reducer model | Planetary reducer |
| Boom type | 6.5M*6 | Slewing ring | 1000.32# |
| Outrigger span | 4.68*4.08m | Engine pump | 50 pump |
| Overall dimension | 9.65*2.18*3.2m | Motor pump | 40 pump |
| Motor Power | 11kw | Center rotation | Electric rotation |
| Lifting speed | Secondary hook 52(116)m/min | Large size | 350*200*8mm |
| Main hook 102m/min | |||
| Swing speed | 0-3 rpm | Boom size | 461*326mm |
| engine model | YN38CRE1 | Rear shift top | Telescopic hind legs |
| Engine power | 95kw | Direction form | Direction Boost |
| Tire model | 825-16 | Brake form | Air brake |
| Driving speed | 80km/h | Gearbox | Wan Li Yang 535 |
| Wheelbase | 3.55m | Axle model | Front axle 1080 rear axle 1069 |
| Self weight | 10.4T | Chassis model | KAMA·35 |
