China Servo Plastic 400mm Blister Forming Machine Station Lunch Box Fully Automatic for sale

Servo Plastic 400mm Blister Forming Machine Station Lunch Box Fully Automatic

Price Negotiable
Price: Negotiate
MOQ: 1
Delivery Time: 20day
Brand: BoHai
Product Description

Fully AutomaticServo Plastic Blister Forming Machine Stationlunch Box



1. Every station is driven by the eccentric crank linkage structure.


2. Feeding and heating part have optoelectronic switch in order to prevent error operating from production process.

3. The toothed chain made of 65#Mn, helping convey sheet. Aluminum rails with water cooling, save water.

M
del
TTF-700AF
Forming Area
700mm x 550 mm
Forming Depth (Max.)
120mm
Sheet thickness
0.2-2.0mm
Forming Speed (Max.)
30times/min
Air pressure
0.6-0.8mpa
Air consumption
3.6 m³/min
Water consumption
0.7 m³/h
Sheet width (Max.)
730mm
Suitable Sheet
PP, PS, HIPS, PET, PVC, PLA etc.
Power supply
AC 380V, 50Hz, Three-phase, Four-wire
Used power
105Kw
Rated power
210Kw
Heating power
118Kw
Procedure
Forming-cutting-stacking
Dimension
L13000*W4700*H2750mm
Weight
About 25T



4. The machine adopts PID temperature system, it shows high precision, and temperature control tolerance ＜1℃.

5. Each servo motor has overload protection for machine’s overworking.

6. Low barycenter and height of finished products as well as steady running ensures easy operation and friendly viewing.

7.There is an alarm function of the sliding doors.
　　
