Tray Food Container Blister Making Machine Plc Vacuum Forming Auto
Price:
Negotiate
MOQ:
1
Delivery Time:
20day
Brand:
BoHai
Product Description
Tray PLC Vacuum Blister Forming Machine Auto For Food Container
The temperature control system of the electric heating furnace adopts full computer intelligent automatic compensation control, one zone control and one digital input, with high precision of fine-tuning, uniform temperature, fast heating (only 3 minutes from 0-400 degrees),
Product Paramenters
|
Machine Frame
|
Square Steel Size 120×120: machine base is complete steel plate with thickness=40mm
|
|
Machine Door
|
The top part of the door with observation window from the operation side, Heating oven could move outside
|
|
Mold Plate
|
QT500 nodular cast iron, pore-free, sand free
|
|
Pillar
|
4-pillar dia.=95mm, 40Cr steel thermal refining, hard chrome plating, mirror finish: Gide bushing Dia.≤200mm, Material: metal
ceramic Zns
|
|
IR Ceramic Heater
|
IR Ceramic Heater, Size: 240×80mm: Top oven: machine direction 10pcs*9zones: Bottom oven: machine direction 9pcs*9zones:
Total: 171pcs, Power: 800W/pcs, made in Germany
|
|
Max. Formng Area
|
760×420mm
|
|
Max. Forming Depth
|
200mm
|
|
Mold Plate Size
|
1350×520mm
|
|
Main Servo Motor
|
P-15KW (4P)
|
|
Stretching Servo Motor
|
7.5KW
|
|
Sheet Feeding Servo Motor
|
4KW
|
|
Sheet Thickness
|
0.25~2.0mm
|
|
Running Speed
|
≤32cycles/min
|
|
Electrical Consumption
|
Approx. 60KW
|
|
Installing Power
|
Approx. 140KW
|
|
Solenoid Valve
|
MAC, USA
|
1. Integrated type, punching and cutting, stacking and counting as one;
2. The most advanced cam structure (equipped with SKF bearings);
