Fast Speed Plastic 2mm Blister Forming Machine Three Station Pp Pvc Pet
Price:
Negotiate
MOQ:
1
Delivery Time:
20day
Brand:
BoHai
Product Description
High Speed Plastic Blister Forming Machine Three Station Pp Pvc Pet
The whole machine adopts full servo control, the positioning is more accurate, and the molding is more stable. The equipment has the advantages of stable operation, low noise, energy saving and environmental protection, and high grade of finished products.
Product Paramenters
|
Max. Forming Area
|
750*480mm
|
650*320mm
|
|
Max. Forming Depth
|
125mm(custom height)
|
|
|
Sheet Thickness
|
0.3-1.8mm
|
|
|
Sheet Width
|
760mm
|
650mm
|
|
Max. Forming Speed
|
35 times/min
|
|
|
Air Pressure
|
0.6-0.8mpa
|
|
|
Air Consumption
|
3.0m³/min
|
2.0m³/min
|
|
Water Consumption
|
0.7m³/h
|
0.5m³/h
|
|
Rated Power
|
140Kw
|
98Kw
|
|
Used Power
|
98Kw
|
69Kw
|
|
Power Supply
|
AC 380V,50Hz, Three-phase, Four-wire
|
|
|
Dimension
|
L8500*W2200*H3100mm
|
L6000*W2000*H2700mm
|
|
Weight
|
About 6.5T
|
About 5T
|
The temperature control system of the electric heating furnace adopts full computer intelligent automatic compensation control. Long life and other advantages. With product data and parameter file memory function. The width of the film feeding chain can be adjusted automatically or separately.
