Astra Tech EV® 3.0 / 3.6 / 4.2 / 4.8 / 5.4 Dental Implant Tiantium Premill Blank Abutment

Astra Tech EV® 3.0 / 3.6 / 4.2 / 4.8 / 5.4 Dental Implant Internal Tiantium Premill Blank Abutment 10mm Engaging

Astra Tech EV®

*3.0mm/ 3.6mm/ 4.2mm/ 4.8mm/ 5.4mm

Material:
Ti 6AI-4V ELI (Supply from Germany)

Feature:

* Simply efficiency
* Precision machined up to ± 5µm
* Benefit from a faster and controlled turnaround time
* Different diameter available of 10mm, 14mm

Pre-milled Abutment Blanks, you can now produce titanium customised abutments with your milling equipment.
Boost your efficiency by using your milling machines and benefit from all major implant connections.

Approved by CE, ISO 9001, ISO 13485

* We also can provide another 3 type of premill as above picture shown. Welcome to further inquire. Thanks.

Points of Astra OsseoSpeed™ EV Dental Implant:

The familiar grade 4 titanium implant body geometry, surface technology and thread pattern is carried forward from the TX series unchanged to the EV implant generation. Implant body diameter and implant/abutment interface connection size have been expanded to six specific diameters of 3.0, 3.6, 4.2, 4.8 and 5.4mm. Each distinct implant body diameter is denominated through a color coding scheme for easy identification as follows. Green 3.0, purple 3.6, yellow 4.2, blue 4.8 and brown is for 5.4mm diameter implants. The implant/abutment interface has been redesigned as a asymmetric heptagon and is therefore not compatible with the previous TX implant series prosthetic components. This feature allows six positions for stock abutments and only one definitive position for custom abutments from Atlantis.
