Dentsply Xive® Titanium Temporary Abutment Compatible 3.0mm/ NP 3.4mm/ RP 3.8mm/ WP 4.5mm/ 5.5mm (Engaging & Non-Engagi

Engaging Titanium Dentsply Xive Dental Implant Temporary

Dentsply Xive® Titanium Temporary Abutment Compatible

3.0mm/ NP 3.4mm/ RP 3.8mm/ WP 4.5mm/ 5.5mm (Engaging & Non-Engaging)

Material:
Ti 6AI-4V ELI (Supply from Germany)

Feature:

* Titanium interface abutment
* 1pc Screw Included

* Precision machined up to ± 5µm
* Combination of high fatigue strength
* Superior level of biocompatibility
* Exterior retentions for more cementation bonding

Specific design ensures a stable union, reinforcing the structure of zirconium in the areas of greatest stress, softening edges and ensuring the service life of the prosthesis.

Furthermore, the saving is also shown in the less time needed when working on the most sensitive part of the prosthesis, the adjustment with the implant.


Approved by CE, ISO 9001, ISO 13485

Product Description

Dentsply XIVE® Titanium Temporary Abutment is designed for the fabrication of temporary screw-retained restorations. Provisional restorations can be made chairside using any standard fabrication technique (e.g., vacuum-formed sheet, prefabricated crown/bridge form, etc.). Bite verification cylinders are precisely machined from titanium alloy and attached to the implant fixture (or implant analog) by a titanium screw or provisional guide pin. Each bite verification cylinder is specific to the restorative platform of the seated implant.

Engaging bite verification cylinders are indicated for single-unit restorations to prevent rotation of the provisional crown. Non-engaging bite verification cylinders are indicated for multi-unit bridges, and therefore avoid the unnecessary anti-rotational implant connection feature to allow for a passive path of insertion.

Accessories

Each Dentsply XIVE® Titanium Temporary Abutment is packaged with a separate provisional screw (Inclusive Guide Pin) and separate retaining screw (Inclusive Titanium Screw) compatible with the restorative instrumentation of the specified implant system. The guide pin should be used throughout the fabrication process. The titanium screw should only be utilized to retain the finished provisional.

Sterility

Dentsply XIVE® Titanium Temporary Abutment are packaged NON-STERILE. Prior to use in the oral environment, they should be cleaned, disinfected, and sterilized firstly.
