Zimmer Screw-Vent® UCLA CoCr Base Castable Abutment Compatibe NP 3.5mm/ RP 4.5mm/ WP 5.7mm
Multi Unit Zimmer Screw Vent® Dental UCLA Implant Abutment
Zimmer Screw-Vent® UCLA CoCr Base Castable Abutment Compatibe
NP 3.5mm/ RP 4.5mm/ WP 5.7mm (Engaging & Non-Engaging)
Material:
CoCr base and castable plastic chimney
Made of CoCr base and castable plastic chimney material for the stable retention of modelling materials
This base is available in two types of platforms: engaging and non-engaging.
Approved by CE, ISO 9001, ISO 13485
|
|
CoCr Base |
A |
B |
C |
D |
||
| 30.017 | NP | Non-engaging | 3,50 | Circular | 1,30 | 4,50 | |
| 31.017 | NP | Engaging | 3,50 | Hex.2,42 | 1,30 | 4,50 | |
| 30.018 | RP | Non-engaging | 4,50 | Circular | 1,30 | 4,90 | |
| 31.018 | RP | Engaging | 4,50 | Hex.3,50 | 1,30 | 4,90 | |
| 30.019 | WP | Non-engaging | 5,10 | Circular | 1,30 | 5,70 | |
| 31.019 | WP | Engaging | 5,10 | Hex.3,05 | 1,30 | 5,70 | |
Points of Zimmer Tapered Screw-Vent® (TSV), Screw-Vent® UCLA:
Fig. 7
UCLA cast on abutments are fabricated with a machined gold abutment/implant interface and a plastic tube processed on to the gold portion of the UCLA. Indexed (hexed) UCLA's (Fig.7, top row) are available for all three platform diameters (3.5, 4.5, 5.7mm) while non indexed UCLA's (Fig.7, bottom row) are only offered for 3.5 and 4.5mm platform diameters. Each abutment is packaged with a final fixation screw to make a complete kit.
