Dentsply XIVE® Impression Coping Transfer Closed/Open Tray Compatible

3.0mm/ NP 3.4mm/ RP 3.8mm/ WP 4.5mm /5.5mm

Material:

Ti 6AI-4V ELI (Supply from Germany)

Feature:
- Titanium interface abutment
- Precision machined up to ± 5µm
- Combination of high fatigue strength
- Superior level of biocompatibility
- Exterior retentions for more cementation bonding

Approved by CE, ISO 9001, ISO 13485

Points of Dentsply Xive Impression Coping Transfer:

Xive® S

Color coded (3.0 brown, 3.4 gray, 3.8 yellow, 4.5 blue, and 5.5 red) impression copings with two flat sides on the body are available as a three component kit for the direct and indirect impression technique. The three components consist of the impression coping body, fixation screw (long or short for direct or indirect impressions respectively) and a plastic cap to fit on top of the impression coping body. This plastic cap engages the two flat sides of the impression coping body through friction only and is meant to be captured and retained in the impression material. For direct impressions with the long fixation screw the top of the plastic cap needs to be punched out before the impression procedure to allow the long fixation screw to pass through the impression tray and the impression cap and coping. Although the plastic cap is part of the kit, it is not essential. The impression coping body itself is offered machined with a 3mm or 5mm collar to accommodate various tissue heights. Xive® S impression copings are compatible with corresponding platform diameter Frialit® implants. Hand tighten with a 1.22mm hex driver.

Xive® TG

Only one platform diameter engaging impression coping for all three body diameter TG implants is needed and available as a indirect or a direct impression coping. The impression copings are silver in color and the fixation screw needs to be purchased separately for the impression coping body.
