Lift Height 3000mm Diesel Forklift Truck With Three Way Catalytic Device
CPCD2500 Load Capacity 2500kgs 2.5 TONS Diesel Forklift Economic Price
- Power system
Equipped with Chinese powerful and reliable engine with excellent environmental performance. Original imported ISUZU, YANMAR, MITSUBISHI and CUMMINS engines as options.
- Hydraulic system
Adopt advanced load sense technology which offers flow for steering system to save energy, protect environment, and lower the system heat.
- Security system
Equipped with OPS or ORS seat and brake switch to prevent incorrect operation and secure the driver and the forklift from all sides.
- Lighting system
Equipped with full set of LED lamps, which are brighter and energy saving.
- Enviromental protection system
Install optional three-way catalytic device to lower the harmful emission beside of low emission engines; Adopt soundproof cotton to ease noise and high exhaust system as option to reduce dust.
| General | ||||
| Model | FD20 | FD25 | ||
| Power Type | Diesel | Diesel | ||
| Load Capacity | kg | 2000 | 2500 | |
| Load centre | mm | 500 | 500 | |
| Tyre | ||||
| Tyre | Pneumatic Tyre | Pneumatic Tyre | ||
| Front Tyre | 7.00-12-12PR | 7.00-12-12PR | ||
| Rear Tyre | 6.00-9-10PR | 6.00-9-10PR | ||
| Overall Dimension | ||||
| Lift Height | mm | 3000 | 3000 | |
| Fork Size | L×W×T | mm | 1070*120*40 | 1070*120*40 |
| Mast Tilt Angle | F/R | . | 6/12 | 6/12 |
| Mast Lowered Height | mm | 2070 | 2070 | |
| Mast Extended Height(with backrest) | mm | 4070 | 4070 | |
| Length to face of fork(Without fork) | mm | 2590 | 2590 | |
| Overall Width | mm | 1150 | 1150 | |
| Overhead Guard Height | mm | 2070 | 2070 | |
